OEM#: Y1372New OEM Original Outright
INVERTER DUTY MOTOR, 184THFW7726, 5HP, 230/460V, 1800RPM, 3PH, 184TC, TEFC by Marathon Motors
Your price:
$1,542.94 eachEstimated to ship by 12/27 if ordered before 10:30 AM EST
OEM#: Y1372INVERTER DUTY MOTOR, 184THFW7726, 5HP, 230/460V, 1800RPM, 3PH, 184TC, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$1,542.94 each
Estimated to ship by 12/27 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Marathon Motors Inverter Duty Motor, Y1372, 184THFW7726, 5HP, 230/460V, 1800RPM, 3PH, 184TC, TEFC
Designed for direct replacement of PMDC or any other variable speed applications where up to a 1000:1 constant torque speed range is required. Typical uses include: machine tools, conveyors, packaging machine, and printing equipment.
Technical Specs
P/N: Y1372 Key Specs
Item
INVERTER DUTY MOTOR, 184THFW7726, 5HP, 230/460V, 1800RPM, 3PH, 184TC, TEFC
OEM
Marathon Motors
OEM #
Y1372
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Fl Amps
13/6.5
60 Hertz Fl Eff
87.50 Percent
60 Hertz Kw
3.7
60 Hertz Sf
1
Ambient Temp C
40
Assembly
F3
Bearing-Drive-End
Ball
Catalog No.
Y1372
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6206
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
184TC
Horsepower
5
Insulation Class
H
Inverter Speed Range
Constant 20:1
Ip Code
43
Is_Motor
Yes
Kva-Code
J
Model Number
184THFW7726
Motor Rpm 60Hz
1800
Mounting
C-Face Removable Base
Nema Design
A
Opposite End Bearing
Ball
Opposite End Bearing Size
6205
Orientation
Horizontal
Phase
3
Rpm
1800
Rpm Range
1701-1800
Starting Type
Inverter Only
Ul
Recognized Construction
Voltage
230/460
Weight In Lbs.
92
Marathon Motors Inverter Duty Motor, Y1372, 184THFW7726, 5HP, 230/460V, 1800RPM, 3PH, 184TC, TEFC
Designed for direct replacement of PMDC or any other variable speed applications where up to a 1000:1 constant torque speed range is required. Typical uses include: machine tools, conveyors, packaging machine, and printing equipment.
