OEM#: U247New OEM Original Outright
PREMIUM EFFICIENCY MOTOR, 3HP, 3600RPM, 208-230/460V, 3PH, 145T FR, DP by Marathon Motors
Your price:
$736.64 eachShip date will be provided after ordering
OEM#: U247PREMIUM EFFICIENCY MOTOR, 3HP, 3600RPM, 208-230/460V, 3PH, 145T FR, DP by Marathon Motors
New OEM Original Outright
Your price:
$736.64 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Product Overview
Marathon Motors Premium Efficiency Motor, U247, 3HP, 3600RPM, 208-230/460V, 3PH, 145T FR, DP
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
Technical Specs
P/N: U247 Key Specs
Item
PREMIUM EFFICIENCY MOTOR, 3HP, 3600RPM, 208-230/460V, 3PH, 145T FR, DP
OEM
Marathon Motors
OEM #
U247
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
8.8/4.4
50 Hertz Hp
3
50 Hertz Kw
2.24
50 Hertz Rpm
3000
50 Hertz Sf
1.15
50 Hertz Voltage
190/380
60 Hertz Kw
2.24
Ambient Temp C
40
Approval-Ce
Y
Assembly
F1 Only
Bearing-Drive-End
6205
Bearing-Opp-Drive-End
6203
Csa
Y
Drive End Bearing Size
6205
Duty
Continuous
Enclosure
DP
Enclosure Type
Open/Drip Proof
Fl Amps
8-7.2/3.6
Fl Efficiency
86.5
Frame
145T
Horsepower
3
Insulation Class
F
Ip Code
22
Is_Motor
Yes
Kva-Code
K
Model Number
145TTDR6002
Motor Rpm 60Hz
3600
Mounting
Rigid
Nameplate Rpm
3600
Nema Design
B
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
3
Rpm Range
3001-3600
Service Factor
1.15
Starting Type
PWS YDRUN
Thermal Protection
Thermostats (Normally Closed)
Ul
Recognized Construction and Protector
Voltage
208-230/460
Weight
46
Marathon Motors Premium Efficiency Motor, U247, 3HP, 3600RPM, 208-230/460V, 3PH, 145T FR, DP
Marathon's XRI Premium Efficiency motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction.
