OEM#: R361New OEM Original Outright
METRIC MOTOR, 63T17FH5402, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC by Marathon Motors
Your price:
$384.98 eachShip date will be provided after ordering
OEM#: R361METRIC MOTOR, 63T17FH5402, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$384.98 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Product Overview
Marathon Motors Metric Motor, R361, 63T17FH5402, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC
Marathon's line of Metric Dimension Motors are designed in IEC Frames from D63 through D200L. The motors are available from stock in 50 Hz or 60 Hz. This means that replacement 60 Hz motors are readily available from Marathon to replace metric motors.
Technical Specs
P/N: R361 Key Specs
Item
METRIC MOTOR, 63T17FH5402, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC
OEM
Marathon Motors
OEM #
R361
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
50 Hertz Fl Amps
1.2/0.6
50 Hertz Hp
1/4
50 Hertz Kw
0.18
50 Hertz Rpm
1500
50 Hertz Sf
1.00
50 Hertz Voltage
200/400
60 Hertz Kw
0.18
Ambient Temp C
40
Approval-Ce
Y
Assembly
F3
Bearing-Drive-End
Ball
Bearing-Opp-Drive-End
Ball
Csa
Y
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
1.0/0.5
Fl Efficiency
68 Percent
Frame
63
Horsepower
1/4
Insulation Class
F
Ip Code
55
Is_Motor
Yes
Kva-Code
H
Model Number
63T17FH5402
Motor Rpm 60Hz
1800
Mounting
Rigid
Nameplate Rpm
1800
Nema Design
B
Orientation
Horizontal
Phase
3
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
230/460
Weight
12
Marathon Motors Metric Motor, R361, 63T17FH5402, 1/4-.18HP, 1800RPM, 230/460V, 3PH, 63 FR, TEFC
Marathon's line of Metric Dimension Motors are designed in IEC Frames from D63 through D200L. The motors are available from stock in 50 Hz or 60 Hz. This means that replacement 60 Hz motors are readily available from Marathon to replace metric motors.
