OEM#: G872New OEM Original Outright
EXPLOSION PROOF MOTOR, 56C17G5328, 1/2HP, 115/208-230V, 1800RPM, 1PH, EPFC by Marathon Motors
Your price:
$662.15 eachEstimated to ship by 12/03 if ordered before 10:30 AM EST
OEM#: G872EXPLOSION PROOF MOTOR, 56C17G5328, 1/2HP, 115/208-230V, 1800RPM, 1PH, EPFC by Marathon Motors
New OEM Original Outright
Your price:
$662.15 each
Estimated to ship by 12/03 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, G872, 56C17G5328, 1/2HP, 115/208-230V, 1800RPM, 1PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: G872 Key Specs
Item
EXPLOSION PROOF MOTOR, 56C17G5328, 1/2HP, 115/208-230V, 1800RPM, 1PH, EPFC
OEM
Marathon Motors
OEM #
G872
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.37
Ambient Temp C
40
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Country of Origin
USA
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPFC
Enclosure Type
Explosion Proof
Fl Amps
8.8/4.4-4.2
Frame
56C
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60
Horsepower
1/2
Insulation Class
F
Ip Code
54
Is_Motor
Yes
Kva-Code
L
Model Number
56C17G5328
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nema Design
B
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1800
Rpm Range
1701-1800
Service Factor
1.15
Starting Type
Cap Start Ind Run
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
115/208-230
Weight
29
Marathon Motors Explosion Proof Motor, G872, 56C17G5328, 1/2HP, 115/208-230V, 1800RPM, 1PH, EPFC
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
