OEM#: E478New OEM Original Outright
SEVERE DUTY MOTOR, 215TTFS6807, 10HP, 230/460V, 3600RPM, 3PH, 215T FR, TEFC by Marathon Motors
Your price:
$1,710.75 eachEstimated to ship by 12/26 if ordered before 10:30 AM EST
OEM#: E478SEVERE DUTY MOTOR, 215TTFS6807, 10HP, 230/460V, 3600RPM, 3PH, 215T FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$1,710.75 each
Estimated to ship by 12/26 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Marathon Motors Severe Duty Motor, E478, 215TTFS6807, 10HP, 230/460V, 3600RPM, 3PH, 215T FR, TEFC
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
Technical Specs
P/N: E478 Key Specs
Item
SEVERE DUTY MOTOR, 215TTFS6807, 10HP, 230/460V, 3600RPM, 3PH, 215T FR, TEFC
OEM
Marathon Motors
OEM #
E478
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
7.5
60 Hertz Rpms
3600
Ambient Temp C
40
Assembly
F1 (F2 Modification Available)
Bearing-Drive-End
6307
Ce
Y
Country of Origin
USA
Csa
Y
Drive End Bearing Size
6307
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
23.6/11.8
Fl Efficiency
91.7
Frame
215T
Hazardous Location
DIVISION 2 T2B
Horsepower
10
Insulation Class
F
Inverter Speed Range
Constant 20:1
Ip Code
54
Is_Motor
Yes
Kva-Code
H
Model Number
215TTFS6807
Motor Rpm 60Hz
3600
Mounting
Rigid
Nema Design
B
Opposite End Bearing
6206
Opposite End Bearing Size
6206
Orientation
Horizontal
Phase
3
Rpm
3600
Rpm Range
3001-3600
Service Factor
1.15
Starting Type
Line or Inverter
Ul
Recognized Construction
Voltage
230/460
Weight
225
Marathon Motors Severe Duty Motor, E478, 215TTFS6807, 10HP, 230/460V, 3600RPM, 3PH, 215T FR, TEFC
Marathon's Severe Duty motors are available from 1 HP to 500 HP. These products are especially designed for those applications requiring protection of the motors from severe environmental operating conditions.
