OEM#: K550New OEM Original Outright
CENTRIFUGAL PUMP MOTOR, 1/2HP, 208-230/460V, 1800RPM, 3PH, 56J FR, TEFC by Marathon Motors
Your price:
$704.04 each
OEM#: K550CENTRIFUGAL PUMP MOTOR, 1/2HP, 208-230/460V, 1800RPM, 3PH, 56J FR, TEFC by Marathon Motors
New OEM Original Outright
Your price:
$704.04 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Centrifugal Pump Motor, K550, 1/2HP, 208-230/460V, 1800RPM, 3PH, 56J FR, TEFC
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
Technical Specs
P/N: K550 Key Specs
Item
CENTRIFUGAL PUMP MOTOR, 1/2HP, 208-230/460V, 1800RPM, 3PH, 56J FR, TEFC
OEM
Marathon Motors
OEM #
K550
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Rpms
1800
Ambient Temp C
40
Bearing-Drive-End
6203
Csa
Y
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
2.3-2.2/1.1
Fl Efficiency
0
Frame
56J
Horsepower
1/2
Insulation Class
B
Is_Motor
Yes
Kva-Code
K
Model Number
5K42HN4133
Motor Rpm 60Hz
1800
Mounting
C-Face Footless
Nema Design
B
Opposite End Bearing
6203
Opposite End Bearing Size
6203
Orientation
Horizontal or Vertical
Phase
3
Rpm
1800
Rpm Range
1701-1800
Service Factor
1
Starting Type
Squirrel Cage Induction
Ul
Y
Voltage
208-230/460
Weight
22
Marathon Motors Centrifugal Pump Motor, K550, 1/2HP, 208-230/460V, 1800RPM, 3PH, 56J FR, TEFC
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
Marathon's pump line of motors includes single or three phase jet pump motors, square flange motors, close-coupled pump motors, and P-Base vertical solid shaft pump motors. The motors are stocked in totally enclosed fan cooled, open drip proof, and many explosion Proof Motors.
