OEM#: H891New OEM Original Outright
EXPLOSION PROOF MOTOR, 5KC49LN6386X, 1/6HP, 115V, 1200RPM, 1PH, EPNV by Marathon Motors
Your price:
$689.61 each
OEM#: H891EXPLOSION PROOF MOTOR, 5KC49LN6386X, 1/6HP, 115V, 1200RPM, 1PH, EPNV by Marathon Motors
New OEM Original Outright
Your price:
$689.61 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Marathon Motors Explosion Proof Motor, H891, 5KC49LN6386X, 1/6HP, 115V, 1200RPM, 1PH, EPNV
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Technical Specs
P/N: H891 Key Specs
Item
EXPLOSION PROOF MOTOR, 5KC49LN6386X, 1/6HP, 115V, 1200RPM, 1PH, EPNV
OEM
Marathon Motors
OEM #
H891
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
60 Hertz Kw
0.13
Ambient Temp C
50
Assembly
F1 Only
Bearing-Drive-End
6203
Ce
N
Drive End Bearing Size
6203
Duty
Continuous
Enclosure
EPNV
Enclosure Type
Explosion Proof
Fl Amps
3.8
Fl Efficiency
55
Frame
56
Hazardous Location
EXP PROOF CL I GR C&D CL II GR F&G T3B
Hertz
60
Horsepower
1/6
Insulation Class
B
Ip Code
54
Is_Motor
Yes
Kva-Code
T
Model Number
5KC49LN6386X
Motor Rpm 60Hz
1200
Mounting
Rigid
Nema Design
No Design Code
Opposite End Bearing
Ball
Opposite End Bearing Size
6203
Orientation
Horizontal
Phase
1
Rotation
CCW
Rpm
1200
Rpm Range
1101-1200
Service Factor
1
Starting Type
Spilt Phase
Thermal Protection
Automatic Protector
Ul
UL Listed
Voltage
115
Weight
28.8
Marathon Motors Explosion Proof Motor, H891, 5KC49LN6386X, 1/6HP, 115V, 1200RPM, 1PH, EPNV
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
Marathon's Hazardous Duty motors are ideal for a wide variety of applications where hazardous fumes or dust may be present. The motors are available in three phase and single phase with ratings, in stock, from 1/4 HP through 300 HP.
