P/N: MS-VPS6M2-DV-WH Key Specs
Item
VACANCY SENSOR PIR 900 SQ FT WHITE
Condition
New OEM Original
Color - Motion Sensing and Dimming
White
Communication Method - Motion Sensing and Dimming
Hard Wired
Coverage Angle - Motion Sensor
180 Degrees
Coverage at Suggested Mounting Height
900 sq. ft.
Description/Special Features
Single Pole, Multi-Location, Manual-On/Auto-Off, No Neutral Required, High-Low Sensitivity Adjustment, Crush/Tamper Resistant Lens
Installation Location - Motion Sensor
Wall Switch Box
Item - Motion Sensing and Dimming
Vacancy Sensor
Lighting Technology
CFL, ELV, Fan Motor, Fluorescent, Halogen, Incandescent, LED, MLV
Max. Capacity @ 120VAC
4.4A (Fan Motor), 6A (CFL, ELV, Fluorescent, Halogen, Incandescent, LED, MLV)
Max. Capacity @ 277VAC
6A (CFL, ELV, Fluorescent, Halogen, Incandescent, LED, MLV)
Operating Voltage - Motion Sensing and Dimming
120 to 277VAC
Sensing Technology
Passive Infrared
Standards
UL and cUL Listed
Suggested Mounting Height - Motion Sensor
4 ft.
Time Delay - Motion Sensor
1 min., 5 min., 15 min., 30 min.
Time Delay Adjustment Method - Motion Sensor
Adjustable
