OEM#: 48-4035

DIGITAL SURVEY METER by Ludlum Measurements

The Ludlum 3000 is a versatile, lightweight, ergonomically-designed instrument used with an external detector for alpha, beta, or gamma radiation survey. Three modes of operation RATE, MAX, and COUNT are available for the user. Measurements can be collected in two sets of units (primary and secondary) for RATE and MAX modes in cps, cpm, Bq, dpm, mR/hr, or µSv/h units. The user can switch between two sets of chosen units by simply pressing the Units button. The standard handle includes the LOG pushbutton that allows the instrument to log up to 1000 data points when activated with the optional Lumic Datalogging Kit. See the Options tab for more information. An internal switch is used to enable or disable the front-panel setup feature to protect desired settings from inadvertent modification. Setup is also available via software available from Ludlum Measurements. User-adjustable settings include calibration constant, dead time correction, efficiency, high voltage, pulse threshold, response time (fast or slow), count time, operational modes, HV current overload level, operational mode (Rate, Max, or Count), and minimum and maximum display levels. The user may also set Primary and Secondary units, unit alarm levels, count units, count alarm levels, and zero pulse protection time limit. This instrument features a large, easily-readable LCD (liquid crystal display), an audio warning tone, and easy, intuitive, user-friendly design. Splash-resistant construction allows the Model 3000 to be used outdoors. The instrument body is made of lightweight, durable, high-impact plastic.

• Large Backlit LCD for Ease of Reading
• Auto Ranging
• Rate, Max, and Count Modes of Operation
• Splash-Resistant Construction for Outdoor Use
• 4-Button Intuitive Interface for Easy Operation
• All-Digital Calibration
• USB Port
• Lighter Weight yet Ruggedly Built
• Built-in ambient light sensor automatically activates low-power LED backlight, unless internal dipswitch is set to continuous-On (will reduce battery life)
• User-selectable from 1 to 60 s, or Auto-Response Rate FAST or SLOW
• Count rate, Exposure/Dose, and Scaler alarm setpoints adjustable over the display range
• High count rate saturation protection prevents false display of lower count rates
• After a user-settable time interval (default 60 seconds) of no pulses from detector, unit will flash a zero reading and the alarm audio will be triggered
• Approximately 750 hours of operation (as low as 100 hours with backlight configured for continuous-on), 16-hour low battery warning
• High-impact plastic with water-resistant rubber seals and separate battery compartment
• NEMA rating of 5x or IP rating of 53
• < 75 dB at 0.6 (2 ft), approximately 4.5 kHz
• Data Logging Handle supplied with built-in push button data logging handle

Display Range:

• 0.0 cps to 99.9 kcps
• 0.00 cpm to 999 kcpm
• 0.00 Bq to 99.9 kBq
• 0.00 dpm to 999 kdpm
• 0.00 µR/h to 999 R/h
• 0.00 µSv/h to 999 Sv/h

Control:

• Press to turn ON
• Tap to acknowledge alarms and silence alarm tone
• Press to reset Sigma Audio alarm
• Hold for OFF
• NORMAL (count rate)
• MAX (captures peak rate)
• COUNT (user-selectable preset count time from 0 to 10 min)
• Turn “click” audio On/Off
• Turn Sigma Audio beep On/Off

• Large, Backlit, Easy-To-Read LCD Screen
• Auto-Ranging
• RATE, MAX, and COUNT Modes of Operation
• Splash-Resistant Construction for Outdoor Use
• All-Digital Calibration
• USB Port
• Lightweight Yet Ruggedly Built
• Simple 5-Button Interface
