OEM#: 5306M-2N5New OEM Original Outright

MEDICAL GRADE POWER STRIP by Leviton

Your price:
$258.42 eachEstimated to ship by 03/14 if ordered before 3:30 PM EST
MEDICAL GRADE POWER STRIP by Leviton
MEDICAL GRADE POWER STRIP by Leviton

OEM#: 5306M-2N5
MEDICAL GRADE POWER STRIP by Leviton

New OEM Original Outright
Your price:
$258.42 each
Estimated to ship by 03/14 if ordered before 3:30 PM EST
Asset Information
Are you an existing customer? Sign in to access your account.
Product Overview

It is a power strip for use with medical equipment and with medical approval under the UL guidelines. They are intended for use inside Patient Care Areas and specifically within the 6 foot perimeter of the patient, known as the Patient Care Vicinity. Medical Grade Power Strips must meet the following criteria:Approval to one or more of the following safety standards: UL 60601-1, IEC 60601-1-1, EN 60601-1, CAN/CSA C22.2 No.601-1-M90, CAN/CSA C22.2 No.601.1S1-94, and CAN/CSA C22.2 No.601.1B-98n. Contain splash-resistant outlet covers that can only be opened with the use of tools (for patient safety), as required by UL to prevent the inadvertent connection of equipment with standard plugs by unqualified personnel. Verify that leakage current and other critical specifications meet medical standards; if there are no leakage-current specifications, the strips may not be approved for medical use. Medical Grade Power Strips should NOT be confused with power strips that simply contain hospital grade plugs and receptacles. However, those types of strips may be used outside of Patient Care Spaces within a health care facility. 6 Outlet.

Technical Specs
P/N: 5306M-2N5 Key Specs
Item
MEDICAL GRADE POWER STRIP
OEM
Leviton
OEM #
5306M-2N5
Condition
New OEM Original
Returnable
No
Warranty
12 Month
Color
White
Cord Length
15 ft
Country of Origin
Mexico
Current Rating
20 A
Frequency Rating
60 Hz
Grade
Medical
HG Outlet Configuration
NEMA 5-20R
HG Plug Configuration
NEMA 5-20P
Leakage Current
<100µA
Material
Powder Coated Steel
Number of Receptacles
6
Operating Temperature
0 to 40 deg C
Outlet Covers
Polypropylene
Power Requirements
125 VAC, 15 A
Standards
CSA, NFPA, UL
Storage Temperature
-10 to +50 deg C
Surge Protection
No
Voltage Rating
125 VAC

It is a power strip for use with medical equipment and with medical approval under the UL guidelines. They are intended for use inside Patient Care Areas and specifically within the 6 foot perimeter of the patient, known as the Patient Care Vicinity. Medical Grade Power Strips must meet the following criteria:Approval to one or more of the following safety standards: UL 60601-1, IEC 60601-1-1, EN 60601-1, CAN/CSA C22.2 No.601-1-M90, CAN/CSA C22.2 No.601.1S1-94, and CAN/CSA C22.2 No.601.1B-98n. Contain splash-resistant outlet covers that can only be opened with the use of tools (for patient safety), as required by UL to prevent the inadvertent connection of equipment with standard plugs by unqualified personnel. Verify that leakage current and other critical specifications meet medical standards; if there are no leakage-current specifications, the strips may not be approved for medical use. Medical Grade Power Strips should NOT be confused with power strips that simply contain hospital grade plugs and receptacles. However, those types of strips may be used outside of Patient Care Spaces within a health care facility. 6 Outlet.
