OEM#: 131549.00New OEM Original Outright

5HP, 230V, 3500RPM, TEFC, RIGID MOUNT, 1.15 SF, 82.5 EFF. by Leeson

Your price:
$1,402.50 eachReady to ship
HomeLeeson13154900
5HP, 230V, 3500RPM, TEFC, RIGID MOUNT, 1.15 SF, 82.5 EFF. by Leeson
5HP, 230V, 3500RPM, TEFC, RIGID MOUNT, 1.15 SF, 82.5 EFF. by Leeson

OEM#: 131549.00
5HP, 230V, 3500RPM, TEFC, RIGID MOUNT, 1.15 SF, 82.5 EFF. by Leeson

New OEM Original Outright
Your price:
$1,402.50 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
General Purpose, Capacitor Start-Capacitor Run Motor: 5HP, 3500 RPM, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, 184 Frame, Rigid Mount, 230V, 1PH, 60HZ, Name Plate Amps 19.8, Continuous duty, 1.15 Service Factor, No thermal protection, Efficiency: 82.5, Efficiency Type: Standard, Ambient 40 C, Selective CCW Rotation, Shaft Length 2-1/4, Shaft Diameter 1 1/8.

Totally enclosed fan cooled (TEFC) enclosure has no vent openings, and is tightly enclosed to prevent the free exchange of air, but is not airtight. An external fan is an integral part of the motor and provides cooling by blowing air around the outside frame of the motor. Suitable for use where exposed to dirt or dampness, but NOT very moist or hazardous (explosive) locations.
Rigid base allows motor to be rigidly mounted on equipment.

Technical Specs
P/N: 131549.00 Key Specs
Item
5HP, 230V, 3500RPM, TEFC, RIGID MOUNT, 1.15 SF, 82.5 EFF.
OEM
Leeson
OEM #
131549.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6206
Compatible With/Replaces - 1
Baldor L3608T, WEG 00536ES1E184T, Marathon I223
Compatible With/Replaces - 2
Baldor, L3608T
Country of Origin
Mexico
Csa
Y
Design
Capacitor Start Capacitor Run
Duty
Continuous
Efficiency Type
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
19.8
Fl Efficiency
82.5
Frame
184T
Frame Material
Rolled Steel
Hertz
60
Horsepower
5
Is_Motor
Yes
Leeson Model No.
C184K34FB6CC
Motor Rpm 60Hz
3500
Mounting
Rigid
Nameplate Rpm
3500
Phase
1
Rotation
CCW
Rpm Range
3001-3600
Service Factor
1.15
Shaft Diameter
1-1/8
Shaft Length
2-1/4
Thermal Protection
No
Ul
Y
Upc
69172001796
Voltage
230
Weight
96
General Purpose, Capacitor Start-Capacitor Run Motor: 5HP, 3500 RPM, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, 184 Frame, Rigid Mount, 230V, 1PH, 60HZ, Name Plate Amps 19.8, Continuous duty, 1.15 Service Factor, No thermal protection, Efficiency: 82.5, Efficiency Type: Standard, Ambient 40 C, Selective CCW Rotation, Shaft Length 2-1/4, Shaft Diameter 1 1/8.

Totally enclosed fan cooled (TEFC) enclosure has no vent openings, and is tightly enclosed to prevent the free exchange of air, but is not airtight. An external fan is an integral part of the motor and provides cooling by blowing air around the outside frame of the motor. Suitable for use where exposed to dirt or dampness, but NOT very moist or hazardous (explosive) locations.
Rigid base allows motor to be rigidly mounted on equipment.
