OEM#: 116343.00New OEM Original Outright
WASHDOWN MOTOR-1/3HP, 115/208-230V, 1725RPM, TENV, RIGID C, 1.15 SF, 72 EFF. by Leeson
Your price:
$1,399.02 eachEstimated to ship by 11/11 if ordered before 10:30 AM EST
OEM#: 116343.00WASHDOWN MOTOR-1/3HP, 115/208-230V, 1725RPM, TENV, RIGID C, 1.15 SF, 72 EFF. by Leeson
New OEM Original Outright
Your price:
$1,399.02 each
Estimated to ship by 11/11 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Premium Washguard All-Stainless Washdown Motors, Single-Phase: 1/3HP, 1725 RPM, Totally-Enclosed Non-Ventilated (TENV) Enclosure, 56H Frame, RIGID C, 115/208-230V, 1PH, 60HZ, Name Plate Amps 5.4/2.7, Continuous duty, 1.15 Service Factor, No thermal protection, Efficiency: 72, Efficiency Type: Standard, Ambient 40 C, Selective CCW Rotation, Shaft Length: 1-7/8", Shaft Diameter: 5/8".
Maximum service in critically clean or corrosive environments
- All exterior components of stainless steel
- Endshields o-ring sealed to frame
- IEEE 841 severe-duty features standard
- Meets demanding pharmaceutical requirements, also excellent for chemical-processing applications
- Meets IP56 enclosure protection
- Incorporates all WASHGUARD mechanical and electrical features
- IRIS™ insulation system
- BISSC certified for baking industry
Technical Specs
P/N: 116343.00 Key Specs
Item
WASHDOWN MOTOR-1/3HP, 115/208-230V, 1725RPM, TENV, RIGID C, 1.15 SF, 72 EFF.
OEM
Leeson
OEM #
116343.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6205
Catalog Number
116343.00
Construction
Stainless Steel
Country of Origin
USA
Csa
Y
Design
Capacitor Start Inductor Run
Duty
Continuous
Efficiency Type
Standard
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
5.4/2.9-2.7
Fl Efficiency
72
Frame
56HC
Hertz
60
Horsepower
1/3
Is_Motor
Yes
Leeson Model No.
NZ6C17VK1BB
Motor Rpm 60Hz
1725
Mounting
C-Face Rigid
Nameplate Amps
5.4/2.7
Phase
1
Rotation
CCW
Rpm
1725
Rpm Range
1701-1800
Service Factor
1.15
Shaft Diameter
5/8
Shaft Length Inches
1-7/8
Thermal Protection
No
Ul
N
Upc
69172030740
Voltage
115/208-230
Weight
35
Premium Washguard All-Stainless Washdown Motors, Single-Phase: 1/3HP, 1725 RPM, Totally-Enclosed Non-Ventilated (TENV) Enclosure, 56H Frame, RIGID C, 115/208-230V, 1PH, 60HZ, Name Plate Amps 5.4/2.7, Continuous duty, 1.15 Service Factor, No thermal protection, Efficiency: 72, Efficiency Type: Standard, Ambient 40 C, Selective CCW Rotation, Shaft Length: 1-7/8", Shaft Diameter: 5/8".
Maximum service in critically clean or corrosive environments
- All exterior components of stainless steel
- Endshields o-ring sealed to frame
- IEEE 841 severe-duty features standard
- Meets demanding pharmaceutical requirements, also excellent for chemical-processing applications
- Meets IP56 enclosure protection
- Incorporates all WASHGUARD mechanical and electrical features
- IRIS™ insulation system
- BISSC certified for baking industry
