OEM#: 111950.00New OEM Original Outright
1/2HP, 115/208-230V, 1725RPM, TEFC, RIGID C MOUNT, 1.0 S.F. by Leeson
Your price:
$1,294.21 eachEstimated to ship by 11/07 if ordered before 10:30 AM EST
OEM#: 111950.001/2HP, 115/208-230V, 1725RPM, TEFC, RIGID C MOUNT, 1.0 S.F. by Leeson
New OEM Original Outright
Your price:
$1,294.21 each
Estimated to ship by 11/07 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Brake Motor: 1/2HP, 1725RPM, 56 Frame, Totally-Enclosed, Fan-Cooled (TEFC), 115/208-230V, 1PH, Continuous duty, No thermal protection, 1.0 Service Factor, Rigid C Mount.
Fail-safe positive, stop and hold brake motor. Brakes are spring set. Load is stopped automatically when power is turned off. Brake motors feature a power off manual release for convenience, and for use in case of a power failure. The manual release resets automatically. The standard brake is manufactured by Stearns. The brake coil leads are brought into the conduit box of the motor for easy connection and may be connected to operate when power to the motor is shut off, or to be actuated independent of power to the motor. Single phase brake coils are 115/230 VAC, 60 Hz.
Technical Specs
P/N: 111950.00 Key Specs
Item
1/2HP, 115/208-230V, 1725RPM, TEFC, RIGID C MOUNT, 1.0 S.F.
OEM
Leeson
OEM #
111950.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6203
Compatible With/Replaces
Baldor KBL3409, Marathon D401
Construction
Rolled Steel
Country of Origin
USA
Csa
Y
Design
Capacitor Start Inductor Run
Duty
Continuous
Efficiency Type
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Efficiency
66
Frame
56
Hertz
60
Horsepower
1/2
Leeson Model No.
C6C17FK20KK
Motor Rpm 60Hz
1725
Mounting
C-Face Rigid
Nameplate Amps
8.8/4.4
Phase
1
Rotation
CCW
Rpm
1725
Rpm Range
1701-1800
Service Factor
1.0
Shaft Diameter
5/8
Shaft Length Inches
1-7/8
Thermal Protection
No
Ul
Y
Upc
69172001038
Voltage
115/208-230
Weight
32
Brake Motor: 1/2HP, 1725RPM, 56 Frame, Totally-Enclosed, Fan-Cooled (TEFC), 115/208-230V, 1PH, Continuous duty, No thermal protection, 1.0 Service Factor, Rigid C Mount.
Fail-safe positive, stop and hold brake motor. Brakes are spring set. Load is stopped automatically when power is turned off. Brake motors feature a power off manual release for convenience, and for use in case of a power failure. The manual release resets automatically. The standard brake is manufactured by Stearns. The brake coil leads are brought into the conduit box of the motor for easy connection and may be connected to operate when power to the motor is shut off, or to be actuated independent of power to the motor. Single phase brake coils are 115/230 VAC, 60 Hz.
