OEM#: 109103.00New OEM Original Outright
DC MOTOR-1 1/2HP, 24V, 1800RPM, TEFC, RIGID C by Leeson
Your price:
$1,443.33 eachEstimated to ship by 12/26 if ordered before 10:30 AM EST
OEM#: 109103.00DC MOTOR-1 1/2HP, 24V, 1800RPM, TEFC, RIGID C by Leeson
New OEM Original Outright
Your price:
$1,443.33 each
Estimated to ship by 12/26 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
DC Motor: 1 1/2HP, 1800 RPM, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, WMS56CZ Frame, Rigid C, 24V, Continuous duty.
Suitable for applications having battery or solar powered operations, or generator supplied low voltage DC. These motors are high torque, continuous duty designs.
- Easy Access Brushes for servicing
- Large over-sized brushes assure longer brush life
- Removable stamp steel base
- Permanently lubricated sealed ball bearings
- High starting Torque
- Linear speed/torque over entire speed range
- Capable of Dynamic braking
- Two-lead connections for simple rotation reversing
Click here to see our full selection of
Technical Specs
P/N: 109103.00 Key Specs
Item
DC MOTOR-1 1/2HP, 24V, 1800RPM, TEFC, RIGID C
OEM
Leeson
OEM #
109103.00
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Catalog No.
109103
Country of Origin
USA
Duty
Continuous
Efficiency Type
Standard
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
WMS56CZ
Frame Material
Rolled Steel
Horsepower
1 1/2
Is_Motor
Yes
Motor Rpm 60Hz
1800
Mounting
C-Face Rigid
Nameplate Rpm
1800
Rpm Range
1701-1800
Upc
69172034745
Voltage
24
Weight
54
DC Motor: 1 1/2HP, 1800 RPM, Totally-Enclosed Fan-Cooled (TEFC) Enclosure, WMS56CZ Frame, Rigid C, 24V, Continuous duty.
Suitable for applications having battery or solar powered operations, or generator supplied low voltage DC. These motors are high torque, continuous duty designs.
- Easy Access Brushes for servicing
- Large over-sized brushes assure longer brush life
- Removable stamp steel base
- Permanently lubricated sealed ball bearings
- High starting Torque
- Linear speed/torque over entire speed range
- Capable of Dynamic braking
- Two-lead connections for simple rotation reversing
Click here to see our full selection of
