OEM#: PFM245G12ANew OEM Original Outright

EXH FAN D/D 24 DIA CFM 9500 115/230 V by JJS Technical Services

Your price:
$1,085.52 eachEstimated to ship by 11/08 if ordered before 4:30 PM EST
HomeJJS Technical Servicespfm245g12a
EXH FAN D/D 24 DIA CFM 9500 115/230 V by JJS Technical Services
EXH FAN D/D 24 DIA CFM 9500 115/230 V by JJS Technical Services

OEM#: PFM245G12A
EXH FAN D/D 24 DIA CFM 9500 115/230 V by JJS Technical Services

New OEM Original Outright
Your price:
$1,085.52 each
Estimated to ship by 11/08 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: PFM245G12A Key Specs
Item
EXH FAN D/D 24 DIA CFM 9500 115/230 V
OEM
JJS Technical Services
OEM #
PFM245G12A
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Agency Compliance
UL Listed Motor
Bearing Type
Permanently Lubricated Ball
CFM @ 0.000 in SP
5600
CFM @ 0.050 in SP
5350
CFM @ 0.100 in SP
5020
CFM @ 0.150 in SP
4540
CFM/Watt @ 0.000 in SP
11.5
CFM/Watt @ 0.050 in SP
10.7
CFM/Watt @ 0.100 in SP
9.9
CFM/Watt @ 0.150 in SP
8.9
Country of Origin
USA
Fan RPM
1,725
Flange Width (Inches)
2-1/4 in
For Use With
General Exhaust Application
Frame Finish
Polished White Polypethylene
Frame Material
Polyethylene
Free Area (Square-Feet)
5.64
Full Load Amps
7/3.5
HP
1/2 hp
Height (Inches)
28-1/4 in
Hz
60
Includes
Aluminum Shutter
Max Ambient Temperature (F)
104 Degrees F
Max Depth (Inches)
26 in
Motor Enclosure
Totally Enclosed Air Over
Motor Insulation
Class F
Motor RPM
825
Motor Type
Permanent Split Capacitor
Mounting Location
Wall
Number of Blades
5
Opening Required H (Inches)
29-1/2 in
Opening Required W (Inches)
29 in
Phase
1
Propeller Diameter (Inches)
24 in
Propeller Material
Galvanized Steel
Shaft Diameter (Inches)
5/8 in
Type
Direct Drive, Preassembled, Adjustable Speed
Venturi Clearance Diameter (Inches)
25 in
Voltage
115/230
Watts
373 W
Width (Inches)
28-1/2 in
