OEM#: U75B-80V-230/1New OEM Original Outright

ELECTRIC AIR COMPRESSOR 7.5 HP 2 STAGE by Jenny

Your price:
$6,985.41 eachShip date will be provided after ordering
HomeJennyu75b80v2301
ELECTRIC AIR COMPRESSOR 7.5 HP 2 STAGE by Jenny
ELECTRIC AIR COMPRESSOR 7.5 HP 2 STAGE by Jenny

OEM#: U75B-80V-230/1
ELECTRIC AIR COMPRESSOR 7.5 HP 2 STAGE by Jenny

New OEM Original Outright
Your price:
$6,985.41 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Technical Specs
P/N: U75B-80V-230/1 Key Specs
Item
ELECTRIC AIR COMPRESSOR 7.5 HP 2 STAGE
OEM
Jenny
OEM #
U75B-80V-230/1
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
(F)NPT Outlet
1/2 in
ASME Tank
Yes
Amps
37.8
Compressor Package Type
Fully Packaged
Control
Pressure Switch/Magnetic Starter
Cylinder Material
Cast Iron
Enclosure
NEMA 1
Finish
Powder Coated
Free Air CFM @ Max. Pressure - Air Compressor
27.2
HP - Air Compressor
7.5 hp
Hz
60
Includes
Magnetic Starter
Input Voltage - Air Compressor
240V AC
Item - Air Compressor
Stationary Air Compressor
Lubrication Type - Air compressor
Splash Lubricated
Motor Type
Open Dripproof
Number of Stages - Air Compressor
2
Off Pressure Switch Setting
175 psi
On Pressure Switch Setting
145 psi
Overall Height
75 in
Overall Length
38 in
Overall Width
26 in
Phase - Electrical
1
Pump Location - Air Compressor
Tank Mounted
Pump Oil Capacity
3.8 qt
Pump RPM
610
Standards
CSA Certified, UL Listed
Style - Air Compressor
Simplex
Tank Size - Air Compressor
80 gal
Tank Style - Air Compressor
Vertical
dBA @ 3 Feet
87
