OEM#: CRY64VUUNew OEM Original Outright

ROLLER FOLLOWER- FULL COMP- INCH, DOUBLE SEALED, 4" OD by IKO International

Your price:
$200.07 eachEstimated to ship by 12/09 if ordered before 10:30 AM EST
HomeIKO Internationalcry64vuu
ROLLER FOLLOWER- FULL COMP- INCH, DOUBLE SEALED, 4" OD by IKO International
ROLLER FOLLOWER- FULL COMP- INCH, DOUBLE SEALED, 4" OD by IKO International

OEM#: CRY64VUU
ROLLER FOLLOWER- FULL COMP- INCH, DOUBLE SEALED, 4" OD by IKO International

New OEM Original Outright
Your price:
$200.07 each
Estimated to ship by 12/09 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview

IKO Roller Follower- Full Comp- Inch, CRY64VUU, Double Sealed, 4" OD

IKO Non-separable Yoke Type Roller Follower is full complement bearing with inner ring, side plates and thick-walled outer ring to withstand heavy rolling or shock loads. Its surface is treated with black oxide coating. Roller Followers are available with Crowned or Cylindrical outer rings. The crowned outer ring relieves edge load created by mounting error and the cylindrical is suitable for applications with large loads or low track surface hardness due to a large contact area with mating track surface. Sufficient lubrication is needed between roller followers and steel track on which cam followers run, to prevent seizure and to reduce friction.

Technical Specs
P/N: CRY64VUU Key Specs
Item
ROLLER FOLLOWER- FULL COMP- INCH, DOUBLE SEALED, 4" OD
OEM
IKO International
OEM #
CRY64VUU
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Bearing Style
Cylindrical OD
Bore Diameter Millimeters (Inch)
31.750 (1-1/4)
Bore Tolerance (Mm)
+0.005 / -0.010
Country of Origin
Japan
Dynamic Load Rating (N)
142000
Needle Construction
Full Compliment
O.D. Tolerance (Mm)
+0 / -0.025
Od Mm (Inch)
101.600 (4)
Oil Hole & Groove
At inner ring
Outer Ring Corner Radius Min. Mm (Inch)
2.381 (3/32)
Outer Ring Width Mm (Inch)
57.150 (2-1/4)
Overall Width Mm (Inch)
58.738 (2.3125)
Prepacked Grease
YES
Radial Clearance
0.045 to 0.070
Retainer
None
Series
CRY
Shaft Dia Drive Fit (Mm)
31.747 to 31.760
Shaft Dia Press Fit (Mm)
31.758 to 31.770
Shaft Dia Push Fit (Mm)
31.727 to 31.740
Side Plate Od (A) Mm (Inch)
71.0 (2.797)
Static Load Rating (N)
317000
Tolerance Outer Ring Width (Mm)
+0 / -0.130
Tolerance Overall Width (Mm)
+0.130 / -0.250
Track Capacity (N)
113000
Type
Double Sealed

IKO Roller Follower- Full Comp- Inch, CRY64VUU, Double Sealed, 4" OD

IKO Non-separable Yoke Type Roller Follower is full complement bearing with inner ring, side plates and thick-walled outer ring to withstand heavy rolling or shock loads. Its surface is treated with black oxide coating. Roller Followers are available with Crowned or Cylindrical outer rings. The crowned outer ring relieves edge load created by mounting error and the cylindrical is suitable for applications with large loads or low track surface hardness due to a large contact area with mating track surface. Sufficient lubrication is needed between roller followers and steel track on which cam followers run, to prevent seizure and to reduce friction.
