OEM#: L8148J1009New OEM Original Outright

AQUASTAT RELAY FOR MILLIVOLT OR LOW VOLTAGE DOES NOT INCLUDE VENT DAMPER PLUG by Honeywell

Your price:
$370.85 eachEstimated to ship by 03/25 if ordered before 4:00 PM EST
HomeHoneywelll8148j10092e861
AQUASTAT RELAY FOR MILLIVOLT OR LOW VOLTAGE DOES NOT INCLUDE VENT DAMPER PLUG by Honeywell
AQUASTAT RELAY FOR MILLIVOLT OR LOW VOLTAGE DOES NOT INCLUDE VENT DAMPER PLUG by Honeywell

OEM#: L8148J1009
AQUASTAT RELAY FOR MILLIVOLT OR LOW VOLTAGE DOES NOT INCLUDE VENT DAMPER PLUG by Honeywell

New OEM Original Outright
Your price:
$370.85 each
Ready to shipReady to Ship
Estimated to ship by 03/25 if ordered before 4:00 PM EST
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: L8148J1009 Key Specs
Item
AQUASTAT RELAY FOR MILLIVOLT OR LOW VOLTAGE DOES NOT INCLUDE VENT DAMPER PLUG
OEM
Honeywell
OEM #
L8148J1009
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Circulator Motor, Burner
Approval
UL, CSA
Connection Type
1/2 Inch Conduit, Quick Connect/Screw
Contact Configuration
SPST
Contact Rating
7.4 Amp at 120 Volt AC/3.7 Amp at 240 Volt AC Full Load, 44.4 Amp at 120 Volt AC/22.2 Amp at 240 Volt AC Locked Rotor (Burner/Circulator), 0.8 Amp at 24 Volt AC (Low Voltage), 0.25 Amp at 1/4 to 12 Volt DC (Millivoltage), 0.2 Amp (Anticipator Setting
Maximum Temperature Rating
150 Deg F with 1.2 Amp 24 Volt/77 Deg F with 1.4 Amp 24 Volt (Load)
Seriesmodel
L8148
Temperature Range
140 to 240 Deg F (High Limit)
Type
4-1/2 Inch Length Capillary, High Limit, Horizontal/Vertical Well Immersion
Technical Specs
P/N: L8148J1009 Key Specs
Item
AQUASTAT RELAY FOR MILLIVOLT OR LOW VOLTAGE DOES NOT INCLUDE VENT DAMPER PLUG
OEM
Honeywell
OEM #
L8148J1009
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Circulator Motor, Burner
Approval
UL, CSA
Connection Type
1/2 Inch Conduit, Quick Connect/Screw
Contact Configuration
SPST
Contact Rating
7.4 Amp at 120 Volt AC/3.7 Amp at 240 Volt AC Full Load, 44.4 Amp at 120 Volt AC/22.2 Amp at 240 Volt AC Locked Rotor (Burner/Circulator), 0.8 Amp at 24 Volt AC (Low Voltage), 0.25 Amp at 1/4 to 12 Volt DC (Millivoltage), 0.2 Amp (Anticipator Setting
Maximum Temperature Rating
150 Deg F with 1.2 Amp 24 Volt/77 Deg F with 1.4 Amp 24 Volt (Load)
Seriesmodel
L8148
Temperature Range
140 to 240 Deg F (High Limit)
Type
4-1/2 Inch Length Capillary, High Limit, Horizontal/Vertical Well Immersion
Technical Specs
P/N: L8148J1009 Key Specs
Item
AQUASTAT RELAY FOR MILLIVOLT OR LOW VOLTAGE DOES NOT INCLUDE VENT DAMPER PLUG
OEM
Honeywell
OEM #
L8148J1009
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Circulator Motor, Burner
Approval
UL, CSA
Connection Type
1/2 Inch Conduit, Quick Connect/Screw
Contact Configuration
SPST
Contact Rating
7.4 Amp at 120 Volt AC/3.7 Amp at 240 Volt AC Full Load, 44.4 Amp at 120 Volt AC/22.2 Amp at 240 Volt AC Locked Rotor (Burner/Circulator), 0.8 Amp at 24 Volt AC (Low Voltage), 0.25 Amp at 1/4 to 12 Volt DC (Millivoltage), 0.2 Amp (Anticipator Setting
Maximum Temperature Rating
150 Deg F with 1.2 Amp 24 Volt/77 Deg F with 1.4 Amp 24 Volt (Load)
Seriesmodel
L8148
Temperature Range
140 to 240 Deg F (High Limit)
Type
4-1/2 Inch Length Capillary, High Limit, Horizontal/Vertical Well Immersion
