OEM#: 180001New OEM Original Outright

WATCHMAN B-STYLE PUMP & MOTOR 1/3 HP 3500 by Hoffman

Your price:
$1,928.50 each
$1,980.00 Savings: $51.50 (3%)
Estimated to ship by 12/23 if ordered before 5:30 PM EST
HomeHoffman180001
WATCHMAN B-STYLE PUMP & MOTOR 1/3 HP 3500 by Hoffman
WATCHMAN B-STYLE PUMP & MOTOR 1/3 HP 3500 by Hoffman

OEM#: 180001
WATCHMAN B-STYLE PUMP & MOTOR 1/3 HP 3500 by Hoffman

New OEM Original Outright
Your price:
$1,928.50 each
$1,980.00 Savings: $51.50 (3%)
Ready to shipReady to Ship
Estimated to ship by 12/23 if ordered before 5:30 PM EST
Asset Information
ADD TO LIST
Product Overview

180001 Hoffman 609PF Watchman Pump 1/3 HP 3500 RPM. 3-11/16" impeller sized for 18 GPM @ 20 PSI, 1/3hp, 3500 RPM, single phase motor with 115/230 volt, 60 cycle, ODP motor.

These pumps are the heart of Domestic Pump condensate-handling equipment. Centriflo centrifugal pumps are basic components of much of our line of condensate-handling equipment. Designed for the rigorous demands of this service, Centriflo pumps require a lower NPSH than conventional pumps. Vertical mounting of the pump saves floor space and gets the motor up above dirt and water. The style PF flange-mounted pumps can be simply bolted to vertical flat surfaces, such as condensate receivers, eliminating suction piping completely. PVF vertical foot mounted are provided with footed NPT connect suction flanges and NPT discharge connections for ease of use in other applications.

Technical Specs
P/N: 180001 Key Specs
Item
WATCHMAN B-STYLE PUMP & MOTOR 1/3 HP 3500
OEM
Hoffman
OEM #
180001
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Construction
Cast Iron
Height Inches
12-5/8
Horsepower
1/3
Length Inches
9
Max Working Pressure Psi
Vented
Model
609PF
Motor Type
ODP
Phase
1
Rpm
3500
Seal Max Temperature [F]
250
Voltage
115 / 208-230
Watts
250
Width Inches
6-1/4

180001 Hoffman 609PF Watchman Pump 1/3 HP 3500 RPM. 3-11/16" impeller sized for 18 GPM @ 20 PSI, 1/3hp, 3500 RPM, single phase motor with 115/230 volt, 60 cycle, ODP motor.

These pumps are the heart of Domestic Pump condensate-handling equipment. Centriflo centrifugal pumps are basic components of much of our line of condensate-handling equipment. Designed for the rigorous demands of this service, Centriflo pumps require a lower NPSH than conventional pumps. Vertical mounting of the pump saves floor space and gets the motor up above dirt and water. The style PF flange-mounted pumps can be simply bolted to vertical flat surfaces, such as condensate receivers, eliminating suction piping completely. PVF vertical foot mounted are provided with footed NPT connect suction flanges and NPT discharge connections for ease of use in other applications.
