OEM#: TX09D70VM1CCANew OEM Original Outright

TFT GRAPHIC LCD DISPLAY WITH ACTIVE MATRIX AND LED by Hitachi Kokusai Electric America Ltd.

Your price:
$48.67 each
$149.58 Savings: $100.91 (67%)
Estimated to ship by 11/27 if ordered before 4:30 PM EST
HomeHitachi Kokusai Electric America Ltd.tx09d70vm1cca
BUYING OPTIONS:
New OEM Original
Outright Purchase
$48.67 each
Warranty: Mfr Warranty
Refurbished
Outright Purchase
$447.67 each
Warranty: 90 Day
TFT GRAPHIC LCD DISPLAY WITH ACTIVE MATRIX AND LED by Hitachi Kokusai Electric America Ltd.
TFT GRAPHIC LCD DISPLAY WITH ACTIVE MATRIX AND LED by Hitachi Kokusai Electric America Ltd.

OEM#: TX09D70VM1CCA
TFT GRAPHIC LCD DISPLAY WITH ACTIVE MATRIX AND LED by Hitachi Kokusai Electric America Ltd.

New OEM Original Outright
Your price:
$48.67 each
$149.58 Savings: $100.91 (67%)
Estimated to ship by 11/27 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Product Overview

The TX09D70VM1CCA is a white transmissive color TFT Graphic LCD Display with active matrix display and light emitting diode (LED) x 6 backlight. It features 40-pin C-MOS interface, R/G/B vertical stripe color pixel arrangement and the surface is anti-glare resistive type touch panel.

  • 6 O'clock Viewing direction

Features
  • 6 O'clock Viewing direction
Technical Specs
P/N: TX09D70VM1CCA Key Specs
Item
TFT GRAPHIC LCD DISPLAY WITH ACTIVE MATRIX AND LED
OEM
Hitachi Kokusai Electric America Ltd.
OEM #
TX09D70VM1CCA
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Active Area
53.64 mm x 71.52 mm
Aspect Ratio
'4:3
Backlight
LED
Contrast Ratio
350:1
Display Appearance
RGB
Display Brightness
320cd/m2
Display Color (Colors)
262000
Display Mode
Normally White-Transmissive
Display Orientation
Portrait
Display Pinout
40 Way Connector
Interface Type
CMOS
Maximum Operating Supply Voltage
3.6 V
Maximum Operating Temperature
70 deg C
Minimum Operating Supply Voltage
3 V
Minimum Operating Temperature
'-20 deg C
Module Size
64 x 86mm
Mounting
Screw
Outline Dimension
64 mm x 86 mm x 8.05 mm
PCB changed
40
Pin Count
40
Pixel Format (Pixels)
320 x 240
Power Rating
742.5 mW
Resolution
320 x 240
Screen Size
3.5 in
Screen Size(Diagonal)
3.5 in
Standards
CE, ROHS
Temperature Rating
-20 to 70 Deg C
Touchscreen
Resistive Touch
Typical Brightness
320 cd/m2
Typical Contrast Ratio
'300:1
Typical Operating Supply Voltage
3.3 V
Typical Power Consumption
'0.66 W
Typical Response Time
30 ms
VGA Size
QVGA
Viewing Angl
140/140
Viewing Angle
75 Deg
Voltage Rating
3.3 V

The TX09D70VM1CCA is a white transmissive color TFT Graphic LCD Display with active matrix display and light emitting diode (LED) x 6 backlight. It features 40-pin C-MOS interface, R/G/B vertical stripe color pixel arrangement and the surface is anti-glare resistive type touch panel.

  • 6 O'clock Viewing direction
