OEM#: 59896180New OEM Original Outright

UPS15-42F CIRCULATOR WATER PUMP, CAST IRON, 220V, 1/25 HP, 3 SPEEDS by Grundfos

Your price:
$234.35 each
$240.95 Savings: $6.60 (3%)
Estimated to ship by 12/23 if ordered before 5:30 PM EST
HomeGrundfos59896180
UPS15-42F CIRCULATOR WATER PUMP, CAST IRON, 220V, 1/25 HP, 3 SPEEDS by Grundfos
UPS15-42F CIRCULATOR WATER PUMP, CAST IRON, 220V, 1/25 HP, 3 SPEEDS by Grundfos

OEM#: 59896180
UPS15-42F CIRCULATOR WATER PUMP, CAST IRON, 220V, 1/25 HP, 3 SPEEDS by Grundfos

New OEM Original Outright
Your price:
$234.35 each
$240.95 Savings: $6.60 (3%)
Ready to shipReady to Ship
Estimated to ship by 12/23 if ordered before 5:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 59896180 Key Specs
Item
UPS15-42F CIRCULATOR WATER PUMP, CAST IRON, 220V, 1/25 HP, 3 SPEEDS
OEM
Grundfos
OEM #
59896180
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Max At 176°F Liquid
176 °F
Approvals Or Certifications
UL, CSA
Capacitor Size - Run
2 µF/400 V
Color
Red
Connection Type
Cast Iron Flange
Flange Standard
USA Oval
Flow U.S. Gpm
0-17.6
Head Feet
0-15.4
Height Inches
6-1/2
Hertz
60
Horsepower
1/25
Housing Material
Cast Iron
Impeller Material
Composite, PES
Length Inches
4
Limited Warranty Years
1
Max. Power Input
92 W
Maximum Ambient Temperature °F
104 °F
Maximum Fluid Temperature °F
230°F
Minimum Fluid Temperature °F
35.6°
Model
UPS15-42F
Motor Protection
Contact
Number Of Poles
2
Number Of Speeds
3
Phase
1
Pipe Connection
2 - Bolt Flange
Port To Port Length Inches
6-1/2
Pos Term Box
9H
Pressure Psi
145
System Type
Closed
Thermal Protection
Internal
Voltage
230
Weight Lbs
4.40
Width Inches
5-1/4
