OEM#: 6703New OEM Original Outright

BRUSHLESS DC MOTOR ECM 1/3 HP 1050 RPM by Genteq

Your price:
$321.83 each
$455.32 Savings: $133.49 (29%)
Ship date will be provided after ordering
HomeGenteq6703
BRUSHLESS DC MOTOR ECM 1/3 HP 1050 RPM by Genteq
BRUSHLESS DC MOTOR ECM 1/3 HP 1050 RPM by Genteq

OEM#: 6703
BRUSHLESS DC MOTOR ECM 1/3 HP 1050 RPM by Genteq

New OEM Original Outright
Your price:
$321.83 each
$455.32 Savings: $133.49 (29%)
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Technical Specs
P/N: 6703 Key Specs
Item
BRUSHLESS DC MOTOR ECM 1/3 HP 1050 RPM
OEM
Genteq
OEM #
6703
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temperature
-40 to 55 Degrees C
Application
Air Handler Systems
Body Diameter
5 2/3 in
Capacitor Required
No
Duty
Continuous
Frame
48
Full Load Amps
2.6
HP
1/3 hp
Hz
60/50
Ins. Class
B
Length Less Shaft
5-1/4 in
Max Ambient Temperature
55 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
ECM
Motor Enclosure Design
Open Air-Over
Motor Frame Material
Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Band
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CCWLE
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Nameplate RPM
1050
Number of Speeds
5
Output Watts
246 W
Overall Length
9-3/16 in
Phase
1
Plug Type
1/4 in and 3/8 in Straight Male Quick Connect Terminals
Shaft Diameter
1/2 in
Shaft Length
3-15/16 in
Standards
CSA Certified, UL Recognized
Voltage
208-230/277
Equivalents
  • 6703: A.O. Smith: Canonical Redirect
