OEM#: 2027268-005

ELECTRONIC BOARD CONTROLLING SECURE DIGITAL DATA CARD, 2 GB by GE Medical Systems Information Technology (GEMSIT)

The Electrocardiogram ECG is a diagnostic test wherein metal electrodes are placed on a patient’s chest. The electrical charges generated by the heart as it beats are detected and displayed on a screen in the form of a graph. The display screen provides the data in text form or waveform. The ECG system has a Secure Digital (SD) data card slot at the rear side where the Electronic Board Controlling Secure Digital Data Card that is used for external storage can be inserted. It can be formatted when used with the system. It is a removable medium used to store the data and system settings. It is a non-volatile memory device. It is based on a 9-pin interface designed to operate in a maximum operating frequency of 100 MHz. The interface of the SD Card allows for easy integration into any design, regardless of which type of microprocessor is being used. In addition to the interface the SD Card offers an alternate communication protocol based on the SPI standard.

• Facilitates the archiving of ECG records
• Protected
• Field Replaceable Unit (FRU) - can be removed and replaced quickly and easily
• Very durable

The Electrocardiogram ECG is a diagnostic test wherein metal electrodes are placed on a patient’s chest. The electrical charges generated by the heart as it beats are detected and displayed on a screen in the form of a graph. The display screen provides the data in text form or waveform. The ECG system has a Secure Digital (SD) data card slot at the rear side where the Electronic Board Controlling Secure Digital Data Card that is used for external storage can be inserted. It can be formatted when used with the system. It is a removable medium used to store the data and system settings. It is a non-volatile memory device. It is based on a 9-pin interface designed to operate in a maximum operating frequency of 100 MHz. The interface of the SD Card allows for easy integration into any design, regardless of which type of microprocessor is being used. In addition to the interface the SD Card offers an alternate communication protocol based on the SPI standard.

• 2027268-004: GE Healthcare: Canonical Redirect
• 2027268-004: Marquette (GEMSIT): Canonical Redirect
• 2027268-004: GE Medical Systems Information Technology (GEMSIT): Item Replacement
• 2027268-005: GE Healthcare: Canonical Redirect
• 2027268-005: Marquette (GEMSIT): Canonical Redirect

• Marquette (GEMSIT)
  • MAC 5500
• GE Medical Systems Information Technology (GEMSIT)
  • MAC 5500
