OEM#: 2023808-002

9.2 M DS1 TO DATASCOPE BALLOON PUMP CABLE by GE Medical Systems Information Technology (GEMSIT)

The DS1 to Datascope Balloon Pump Cable is designed for the Patient Data Module (PDM) of the patient monitoring system. The purpose of this cable is to provide ECG (Electrocardiogram) and BP (Blood Pressure) sync interface from the PDM to Datascope Intra-Aortic balloon pumps and to provide an ECG and BP sync interface from the PDM to two phone plugs. The cable uses 1/4 Inch auxiliary inputs instead of the patient cable input and has 9-pin DSI style connector (P1) and two 1/4" mono phone plugs (P2andP3). The two 1/4" mono plugs are color-coded as P2-Green for ECG and P3-Red for pressure for more positive identification. This cable provides two high level analog output signals ECG and arterial pressure from the PDM. The GE product is an innovation and technology which fits well into versatile customer needs. It is manufactured using high precision techniques which helps to achieve a good surface finish as well as good product consistency. The part is diligently designed for high performance and reliability. It is securely packaged inside a high quality packing box to avoid physical damage during transit and labeled with details about the product, Quality Assurance (QA) seal and shipment details.

• Enhanced durability and reliability
• Color coded mono plugs for more positive identification
• Individually packed
• compliant to IPC/WHMA A-620 standards
