OEM#: TP400/700

TEMPERATURE PROBE SIMULATOR by Fogg System Company, Inc.

The TP400/700 Temperature Probe Simulator is intended primarily for setup, demonstration, and troubleshooting temperature measuring instruments that use the YSI 400 and/or 700 Series, or equivalent Temperature Probes. When substituted for the probe, the Simulator provides precise and stable outputs for setup and testing of temperature measuring instruments. Since the Simulator eliminates the probe as a variable, you can quickly determine whether measurement problems are caused by the probe or the measuring instrument. Other useful applications include training personnel in the correct setup and operation of temperature measuring instruments and in quickly identifying a malfunctioning temperature probe.

Fogg Temperature Probe Simulators contain thermally stable precision resistive networks. A rotary switch permits selection of eleven temperatures from 0°C to 45°C with an accuracy of ±0.05°C at each setting. Simulated Temperatures are designated in both degrees Fahrenheit and Centigrade.

Cables are available to connect the Simulator to most temperature measuring instruments. Typical instruments are electronic thermometers, patient monitors, infant incubators, hypothermia systems, and temperature controlled analytical laboratory instruments.

Excitation Voltage:

• Same as for the appropriate temperature probe, up to 0.50 Volts ac or dc, supplied by the temperature measuring instrument

Simulated Temperatures:

• Switch selectable in 11 steps. °C /°F; 0/32, 20/68, 25/77, 30/86, 35/95, 36/96.8, 37/98.6, 38/100.4, 39/102.2, 40/104, 45/113

• Simulates YSI 400 and 700 Series Probes simultaneously at 11 temperatures from ZERO to 45 deg C
• Accurate within ±0.05 deg C at each setting
• Cables are available to connect the Simulator to many temperature measuring instruments

The TP400/700 Temperature Probe Simulator is intended primarily for setup, demonstration, and troubleshooting temperature measuring instruments that use the YSI 400 and/or 700 Series, or equivalent Temperature Probes. When substituted for the probe, the Simulator provides precise and stable outputs for setup and testing of temperature measuring instruments. Since the Simulator eliminates the probe as a variable, you can quickly determine whether measurement problems are caused by the probe or the measuring instrument. Other useful applications include training personnel in the correct setup and operation of temperature measuring instruments and in quickly identifying a malfunctioning temperature probe.

Fogg Temperature Probe Simulators contain thermally stable precision resistive networks. A rotary switch permits selection of eleven temperatures from 0°C to 45°C with an accuracy of ±0.05°C at each setting. Simulated Temperatures are designated in both degrees Fahrenheit and Centigrade.

Cables are available to connect the Simulator to most temperature measuring instruments. Typical instruments are electronic thermometers, patient monitors, infant incubators, hypothermia systems, and temperature controlled analytical laboratory instruments.

Excitation Voltage:

• Same as for the appropriate temperature probe, up to 0.50 Volts ac or dc, supplied by the temperature measuring instrument

Simulated Temperatures:

• Switch selectable in 11 steps. °C /°F; 0/32, 20/68, 25/77, 30/86, 35/95, 36/96.8, 37/98.6, 38/100.4, 39/102.2, 40/104, 45/113
