OEM#: 2249768New OEM Original Outright

UNIVERSAL PRESSURE METER TESTER by Fluke Electronics Corp (Biomedical Div.)

Your price:
$2,463.75 eachShip date will be provided after ordering
HomeFluke Electronics Corp (Biomedical Div.)2249768
UNIVERSAL PRESSURE METER TESTER by Fluke Electronics Corp (Biomedical Div.)
UNIVERSAL PRESSURE METER TESTER by Fluke Electronics Corp (Biomedical Div.)

OEM#: 2249768
UNIVERSAL PRESSURE METER TESTER by Fluke Electronics Corp (Biomedical Div.)

New OEM Original Outright
Your price:
$2,463.75 each
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Product Overview

Operating Range

  • 698 to 802 mmHg
  • 949 to 1090 cmH2O
  • 374 to 429 inH2O
  • 13.50 to 15.50 PSI
  • 13.5 to 100 PSI

Units of measure

  • mmHg, cmH2O, PSI, inH2O

Temperature operating requirements

  • 0 °C to 30 °C (32 °F to 86 °F)

Display/Control

  • 0.5 in LCD with LO BATT and negative polarity indication

Data outputs

  • V/psi (all ranges except 100 psi)
  • 0.01 V/psi for 100 psi range

Power Supply

  • 9 V Alkaline Battery

Features
  • Handheld, Battery operated
  • Five selectable scale ranges
  • Voltage output to drive a recorder for assessing electronics of pressure measurement circuit
  • Capability to test ophthalmology equipment, lasers, dialysis machines, automatic tourniquets, drainage devices, IV pumps, pressure gauges, ventilators, diagnostic, surgical suction devices, and more
  • Air or liquid measurement
Technical Specs
P/N: 2249768 Key Specs
Item
UNIVERSAL PRESSURE METER TESTER
OEM
Fluke Electronics Corp (Biomedical Div.)
OEM #
2249768
Condition
New OEM Original
Returnable
No
Warranty
12 Month
Accuracy
1% of full scale
Data Outputs
V/psi (all ranges except 100 psi); 0.01 V/psi for 100 psi range
Dimensions
3.6 in W x 5.75 in D x 1.9 in H
Display/Control
0.5 in LCD with LO BATT and negative polarity indication
Operating Range
-698 mmHg to 802 mmHg; -949 cmH 2 O to 1090 cmH 2 O; -374 inH 2 O to 429 inH 2 O; -13.50 PSI to 15.50 PSI; -13.5 PSI to 100 PSI
Power
9 V Alkaline Battery
Temperature Requirements
0 to 30 Deg C
Units of Measure
MmHg; cmH 2 O; PSI; inH 2 O
Weight
1 lb
Fitments

Operating Range

  • 698 to 802 mmHg
  • 949 to 1090 cmH2O
  • 374 to 429 inH2O
  • 13.50 to 15.50 PSI
  • 13.5 to 100 PSI

Units of measure

  • mmHg, cmH2O, PSI, inH2O

Temperature operating requirements

  • 0 °C to 30 °C (32 °F to 86 °F)

Display/Control

  • 0.5 in LCD with LO BATT and negative polarity indication

Data outputs

  • V/psi (all ranges except 100 psi)
  • 0.01 V/psi for 100 psi range

Power Supply

  • 9 V Alkaline Battery

    • Fluke Electronics Corp (Biomedical Div.)
      • DPM2 PLUS
      • DPM SERIES
    Product Overview

    Operating Range

    • 698 to 802 mmHg
    • 949 to 1090 cmH2O
    • 374 to 429 inH2O
    • 13.50 to 15.50 PSI
    • 13.5 to 100 PSI

    Units of measure

    • mmHg, cmH2O, PSI, inH2O

    Temperature operating requirements

    • 0 °C to 30 °C (32 °F to 86 °F)

    Display/Control

    • 0.5 in LCD with LO BATT and negative polarity indication

    Data outputs

    • V/psi (all ranges except 100 psi)
    • 0.01 V/psi for 100 psi range

    Power Supply

    • 9 V Alkaline Battery

    Features
    • Handheld, Battery operated
    • Five selectable scale ranges
    • Voltage output to drive a recorder for assessing electronics of pressure measurement circuit
    • Capability to test ophthalmology equipment, lasers, dialysis machines, automatic tourniquets, drainage devices, IV pumps, pressure gauges, ventilators, diagnostic, surgical suction devices, and more
    • Air or liquid measurement
    Technical Specs
    P/N: 2249768 Key Specs
    Item
    UNIVERSAL PRESSURE METER TESTER
    OEM
    Fluke Electronics Corp (Biomedical Div.)
    OEM #
    2249768
    Condition
    New OEM Original
    Returnable
    No
    Warranty
    12 Month
    Accuracy
    1% of full scale
    Data Outputs
    V/psi (all ranges except 100 psi); 0.01 V/psi for 100 psi range
    Dimensions
    3.6 in W x 5.75 in D x 1.9 in H
    Display/Control
    0.5 in LCD with LO BATT and negative polarity indication
    Operating Range
    -698 mmHg to 802 mmHg; -949 cmH 2 O to 1090 cmH 2 O; -374 inH 2 O to 429 inH 2 O; -13.50 PSI to 15.50 PSI; -13.5 PSI to 100 PSI
    Power
    9 V Alkaline Battery
    Temperature Requirements
    0 to 30 Deg C
    Units of Measure
    MmHg; cmH 2 O; PSI; inH 2 O
    Weight
    1 lb
    Fitments

    Operating Range

    • 698 to 802 mmHg
    • 949 to 1090 cmH2O
    • 374 to 429 inH2O
    • 13.50 to 15.50 PSI
    • 13.5 to 100 PSI

    Units of measure

    • mmHg, cmH2O, PSI, inH2O

    Temperature operating requirements

    • 0 °C to 30 °C (32 °F to 86 °F)

    Display/Control

    • 0.5 in LCD with LO BATT and negative polarity indication

    Data outputs

    • V/psi (all ranges except 100 psi)
    • 0.01 V/psi for 100 psi range

    Power Supply

    • 9 V Alkaline Battery

      • Fluke Electronics Corp (Biomedical Div.)
        • DPM2 PLUS
        • DPM SERIES
      Product Overview

      Operating Range

      • 698 to 802 mmHg
      • 949 to 1090 cmH2O
      • 374 to 429 inH2O
      • 13.50 to 15.50 PSI
      • 13.5 to 100 PSI

      Units of measure

      • mmHg, cmH2O, PSI, inH2O

      Temperature operating requirements

      • 0 °C to 30 °C (32 °F to 86 °F)

      Display/Control

      • 0.5 in LCD with LO BATT and negative polarity indication

      Data outputs

      • V/psi (all ranges except 100 psi)
      • 0.01 V/psi for 100 psi range

      Power Supply

      • 9 V Alkaline Battery

      Features
      • Handheld, Battery operated
      • Five selectable scale ranges
      • Voltage output to drive a recorder for assessing electronics of pressure measurement circuit
      • Capability to test ophthalmology equipment, lasers, dialysis machines, automatic tourniquets, drainage devices, IV pumps, pressure gauges, ventilators, diagnostic, surgical suction devices, and more
      • Air or liquid measurement
      Technical Specs
      P/N: 2249768 Key Specs
      Item
      UNIVERSAL PRESSURE METER TESTER
      OEM
      Fluke Electronics Corp (Biomedical Div.)
      OEM #
      2249768
      Condition
      New OEM Original
      Returnable
      No
      Warranty
      12 Month
      Accuracy
      1% of full scale
      Data Outputs
      V/psi (all ranges except 100 psi); 0.01 V/psi for 100 psi range
      Dimensions
      3.6 in W x 5.75 in D x 1.9 in H
      Display/Control
      0.5 in LCD with LO BATT and negative polarity indication
      Operating Range
      -698 mmHg to 802 mmHg; -949 cmH 2 O to 1090 cmH 2 O; -374 inH 2 O to 429 inH 2 O; -13.50 PSI to 15.50 PSI; -13.5 PSI to 100 PSI
      Power
      9 V Alkaline Battery
      Temperature Requirements
      0 to 30 Deg C
      Units of Measure
      MmHg; cmH 2 O; PSI; inH 2 O
      Weight
      1 lb
      Fitments

      Operating Range

      • 698 to 802 mmHg
      • 949 to 1090 cmH2O
      • 374 to 429 inH2O
      • 13.50 to 15.50 PSI
      • 13.5 to 100 PSI

      Units of measure

      • mmHg, cmH2O, PSI, inH2O

      Temperature operating requirements

      • 0 °C to 30 °C (32 °F to 86 °F)

      Display/Control

      • 0.5 in LCD with LO BATT and negative polarity indication

      Data outputs

      • V/psi (all ranges except 100 psi)
      • 0.01 V/psi for 100 psi range

      Power Supply

      • 9 V Alkaline Battery

        • Fluke Electronics Corp (Biomedical Div.)
          • DPM2 PLUS
          • DPM SERIES
