OEM#: 137432New OEM Original Outright

MOTOR 1 HP 3 450 RPM 230V by Flint Walling

Your price:
$833.56 eachEstimated to ship by 12/09 if ordered before 4:30 PM EST
HomeFlint Walling137432
MOTOR 1 HP 3 450 RPM 230V by Flint Walling
MOTOR 1 HP 3 450 RPM 230V by Flint Walling

OEM#: 137432
MOTOR 1 HP 3 450 RPM 230V by Flint Walling

New OEM Original Outright
Your price:
$833.56 each
Estimated to ship by 12/09 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 137432 Key Specs
Item
MOTOR 1 HP 3 450 RPM 230V
OEM
Flint Walling
OEM #
137432
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Country of Origin
USA
Diameter
3-3/4 in
Diaphragm Type
Pressure Equalizing
Full Load Amps
8.2
HP
1
Height
12-1/8 in
Hz
60
Lead Length
48 in
Max Ambient Temperature
86 Degrees F
Max SF Amps
10.4
Motor Application
Pump
Motor Bearings
Sleeve
Motor Design
Split-Phase
Motor Enclosure Design
Totally Enclosed Nonventilated
Motor Service Factor
1.4
Motor Shaft Rotation
CWSE
Motor Sub Application
Deep Well Submersible Pump
Motor Thermal Protection
Auto
Nameplate RPM
3450
Number of Wires
3
Overload Relay Required
No
Phase
1
RPM Range
3001-3600
Shaft Material
Stainless Steel
Shell Material
Stainless Steel
Standards
CSA (C22.2 No. 100-14), NSF/ANSI 61
Starter Required
No
Stator Type
Hermetically Sealed
Thrust Rating
700 lb
Voltage
230
