OEM#: D608New OEM Original Outright

HVAC 3.3 IN MOTOR 1/50 HP 230V CW by Fasco

Your price:
$127.27 each
$131.29 Savings: $4.02 (3%)
Ship date will be provided after ordering
HomeFascod608
HVAC 3.3 IN MOTOR 1/50 HP 230V CW by Fasco
HVAC 3.3 IN MOTOR 1/50 HP 230V CW by Fasco

OEM#: D608
HVAC 3.3 IN MOTOR 1/50 HP 230V CW by Fasco

New OEM Original Outright
Your price:
$127.27 each
$131.29 Savings: $4.02 (3%)
Ship date will be provided after ordering
Asset Information
ADD TO LIST
Technical Specs
P/N: D608 Key Specs
Item
HVAC 3.3 IN MOTOR 1/50 HP 230V CW
OEM
Fasco
OEM #
D608
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
HVAC/R
Body Diameter
3.3 in
Duty
Continuous
Frame
3.3
Full Load Amps
0.64
HP
1/50 hp
Hz
60/50
Ins. Class
B
Length Less Shaft
3-3/4 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Sleeve
Motor Design
Shaded Pole
Motor Enclosure Design
Open Dripproof
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CWSE
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Pattern
2-7/8 x 2-7/8
Mounting Stud Location
4/Both Ends
Nameplate RPM
2500/3000
Number of Shafts
1
Number of Speeds
1
Phase
1
Shaft Diameter
1/4 in
Shaft Length
1-5/16 in
Standards
CSA Certified (LR36496), UL Recognized (E40513)
Stud/Base Mtg. Pattern
2-7/8 in x 2-7/8 in
Voltage
230
