OEM#: D1092New OEM Original Outright

ROOM AIR CONDITIONER MOTOR 1/3 HP 115V by Fasco

Your price:
$194.41 each
$209.84 Savings: $15.43 (7%)
Estimated to ship by 12/25 if ordered before 5:30 PM EST
HomeFascod1092
ROOM AIR CONDITIONER MOTOR 1/3 HP 115V by Fasco
ROOM AIR CONDITIONER MOTOR 1/3 HP 115V by Fasco

OEM#: D1092
ROOM AIR CONDITIONER MOTOR 1/3 HP 115V by Fasco

New OEM Original Outright
Your price:
$194.41 each
$209.84 Savings: $15.43 (7%)
Ready to shipReady to Ship
Estimated to ship by 12/25 if ordered before 5:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: D1092 Key Specs
Item
ROOM AIR CONDITIONER MOTOR 1/3 HP 115V
OEM
Fasco
OEM #
D1092
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Room A/C
Body Diameter
5 in
Bolt Circle Diameter
4-5/8 in
Capacitor Required
2MDV6
Frame
42
Full Load Amps
3.4
HP
1/3
Hz
60
Ins. Class
B
Length Less Shaft
3-5/8 in
Manufacturers Warranty Length
1 yr
Max Ambient Temperature
40 Degrees C
Motor Bearings
Sleeve
Motor Design
Permanent Split Capacitor
Motor Enclosure Design
Open Air-Over
Motor Mounting Type
Stud
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CWLE
Motor Sub Application
Direct Drive Fan/Blower
Motor Thermal Protection
Auto
Mounting Stud Pattern
4 x 4 in
Nameplate RPM
1675/1080
Number of Shafts
2
Number of Speeds
2
OEM Replacement Brand
Coleman
Overall Length
15 in
Phase
1
Replacement For
Coleman Mfr. No. 1468-306, 1468-3069
Shaft Diameter
1/2 in
Shaft Length
3 1/2 in, 7 15/16 in
Standards
CSA (LR34751), UL (E58977)
Stud Size
8-32 x 1/2 in
Voltage
115
