VIRTUAL SERVICES PLATFORM 8404C-AC, SWITCH, L3, RACK-MOUNTABLE, GOVERNMENT GSA, TAA COMPLIANT
VIRTUAL SERVICES PLATFORM 8404C-AC, SWITCH, L3, RACK-MOUNTABLE, GOVERNMENT GSA, TAA COMPLIANT
Product Overview
Flexible, compact form-factor Ethernet switch designed to deliver sophisticated functionality in versatile deployment scenarios for businesses that range from mid-market up to mid-sized enterprises. The VSP 8404 Ethernet switch provides four front-panel slots that support the flexible deployment of high-density VSP 8400 series Ethernet switch modules. By default, the VSP 8404 is a "zero port" system, with a chassis that integrates the switching fabric and all associated control and management electronics. Ethernet interfaces are delivered by the addition of one or more fieldreplaceable and hot-swappable Ethernet Switch Modules (ESMs).
Features
- High-performance 10/40 Gigabit Ethernet Switch
- Flexible pay-as-you-grow semi-modular design
- Flexibly supports high-density 10 Gigabit, 40 Gigabit, and Combo modules
- At home in both the Campus Core and as the Spine Switch in a Data Center Spine/Leaf Top-of-Rack deployment
- Efficient compact formfactor that reduces power and footprint consumption
- Supports both conventional Routed IP and/or Fabric-based network deployments
- Delivers high-end functionality, performance, and scalability while helping to avoid the traditional 'Chassis Tax'
Technical Specs
P/N: EC8400A02-E6GS Key Specs
Item
VIRTUAL SERVICES PLATFORM 8404C-AC, SWITCH, L3, RACK-MOUNTABLE, GOVERNMENT GSA, TAA COMPLIANT
OEM
Extreme Network
OEM #
EC8400A02-E6GS
Returnable
No
Warranty
Capacity
Virtual interfaces (VLANs): 4059 ARP entries: 32000 Multiple Spanning Tree Protocol instances: 12 IP router interfaces: 506 IPv4 routes (static): 5000 RIP routes: 15488 OSPF instances: 500 OSPF routes: 15488 OSPF Areas: 80 BGP peers: 12 BGP
Compliant Standards
IEEE 802.1Q, IEEE 802.1aq
Device Type
Switch - L3
Enclosure Type
Rack-mountable
Jumbo Frame Support
9600 bytes
MAC Address Table Size
224000 entries
Performance
Switching fabric bandwidth: 2.56 Tbps Forwarding performance: 1.428 Mpps Latency: 480 ns
Power
AC 120/230 V (50/60 Hz)
Power Redundancy
Optional
Pricing Type
Government GSA
Routing Protocol
OSPF, RIP, IS-IS, BGP, IGMP, VRRP, PIM-SM, static IP routing, OSPFv3, PIM-SSM, ECMP
TAA Compliant
Yes
Flexible, compact form-factor Ethernet switch designed to deliver sophisticated functionality in versatile deployment scenarios for businesses that range from mid-market up to mid-sized enterprises. The VSP 8404 Ethernet switch provides four front-panel slots that support the flexible deployment of high-density VSP 8400 series Ethernet switch modules. By default, the VSP 8404 is a "zero port" system, with a chassis that integrates the switching fabric and all associated control and management electronics. Ethernet interfaces are delivered by the addition of one or more fieldreplaceable and hot-swappable Ethernet Switch Modules (ESMs).
Product Overview
Flexible, compact form-factor Ethernet switch designed to deliver sophisticated functionality in versatile deployment scenarios for businesses that range from mid-market up to mid-sized enterprises. The VSP 8404 Ethernet switch provides four front-panel slots that support the flexible deployment of high-density VSP 8400 series Ethernet switch modules. By default, the VSP 8404 is a "zero port" system, with a chassis that integrates the switching fabric and all associated control and management electronics. Ethernet interfaces are delivered by the addition of one or more fieldreplaceable and hot-swappable Ethernet Switch Modules (ESMs).
Features
- High-performance 10/40 Gigabit Ethernet Switch
- Flexible pay-as-you-grow semi-modular design
- Flexibly supports high-density 10 Gigabit, 40 Gigabit, and Combo modules
- At home in both the Campus Core and as the Spine Switch in a Data Center Spine/Leaf Top-of-Rack deployment
- Efficient compact formfactor that reduces power and footprint consumption
- Supports both conventional Routed IP and/or Fabric-based network deployments
- Delivers high-end functionality, performance, and scalability while helping to avoid the traditional 'Chassis Tax'
Technical Specs
P/N: EC8400A02-E6GS Key Specs
Item
VIRTUAL SERVICES PLATFORM 8404C-AC, SWITCH, L3, RACK-MOUNTABLE, GOVERNMENT GSA, TAA COMPLIANT
OEM
Extreme Network
OEM #
EC8400A02-E6GS
Returnable
No
Warranty
Capacity
Virtual interfaces (VLANs): 4059 ARP entries: 32000 Multiple Spanning Tree Protocol instances: 12 IP router interfaces: 506 IPv4 routes (static): 5000 RIP routes: 15488 OSPF instances: 500 OSPF routes: 15488 OSPF Areas: 80 BGP peers: 12 BGP
Compliant Standards
IEEE 802.1Q, IEEE 802.1aq
Device Type
Switch - L3
Enclosure Type
Rack-mountable
Jumbo Frame Support
9600 bytes
MAC Address Table Size
224000 entries
Performance
Switching fabric bandwidth: 2.56 Tbps Forwarding performance: 1.428 Mpps Latency: 480 ns
Power
AC 120/230 V (50/60 Hz)
Power Redundancy
Optional
Pricing Type
Government GSA
Routing Protocol
OSPF, RIP, IS-IS, BGP, IGMP, VRRP, PIM-SM, static IP routing, OSPFv3, PIM-SSM, ECMP
TAA Compliant
Yes
Flexible, compact form-factor Ethernet switch designed to deliver sophisticated functionality in versatile deployment scenarios for businesses that range from mid-market up to mid-sized enterprises. The VSP 8404 Ethernet switch provides four front-panel slots that support the flexible deployment of high-density VSP 8400 series Ethernet switch modules. By default, the VSP 8404 is a "zero port" system, with a chassis that integrates the switching fabric and all associated control and management electronics. Ethernet interfaces are delivered by the addition of one or more fieldreplaceable and hot-swappable Ethernet Switch Modules (ESMs).
Product Overview
Flexible, compact form-factor Ethernet switch designed to deliver sophisticated functionality in versatile deployment scenarios for businesses that range from mid-market up to mid-sized enterprises. The VSP 8404 Ethernet switch provides four front-panel slots that support the flexible deployment of high-density VSP 8400 series Ethernet switch modules. By default, the VSP 8404 is a "zero port" system, with a chassis that integrates the switching fabric and all associated control and management electronics. Ethernet interfaces are delivered by the addition of one or more fieldreplaceable and hot-swappable Ethernet Switch Modules (ESMs).
Features
- High-performance 10/40 Gigabit Ethernet Switch
- Flexible pay-as-you-grow semi-modular design
- Flexibly supports high-density 10 Gigabit, 40 Gigabit, and Combo modules
- At home in both the Campus Core and as the Spine Switch in a Data Center Spine/Leaf Top-of-Rack deployment
- Efficient compact formfactor that reduces power and footprint consumption
- Supports both conventional Routed IP and/or Fabric-based network deployments
- Delivers high-end functionality, performance, and scalability while helping to avoid the traditional 'Chassis Tax'
How can we
improve our item listing
?Technical Specs
P/N: EC8400A02-E6GS Key Specs
Item
VIRTUAL SERVICES PLATFORM 8404C-AC, SWITCH, L3, RACK-MOUNTABLE, GOVERNMENT GSA, TAA COMPLIANT
OEM
Extreme Network
OEM #
EC8400A02-E6GS
Returnable
No
Warranty
Capacity
Virtual interfaces (VLANs): 4059 ARP entries: 32000 Multiple Spanning Tree Protocol instances: 12 IP router interfaces: 506 IPv4 routes (static): 5000 RIP routes: 15488 OSPF instances: 500 OSPF routes: 15488 OSPF Areas: 80 BGP peers: 12 BGP
Compliant Standards
IEEE 802.1Q, IEEE 802.1aq
Device Type
Switch - L3
Enclosure Type
Rack-mountable
Jumbo Frame Support
9600 bytes
MAC Address Table Size
224000 entries
Performance
Switching fabric bandwidth: 2.56 Tbps Forwarding performance: 1.428 Mpps Latency: 480 ns
Power
AC 120/230 V (50/60 Hz)
Power Redundancy
Optional
Pricing Type
Government GSA
Routing Protocol
OSPF, RIP, IS-IS, BGP, IGMP, VRRP, PIM-SM, static IP routing, OSPFv3, PIM-SSM, ECMP
TAA Compliant
Yes
Flexible, compact form-factor Ethernet switch designed to deliver sophisticated functionality in versatile deployment scenarios for businesses that range from mid-market up to mid-sized enterprises. The VSP 8404 Ethernet switch provides four front-panel slots that support the flexible deployment of high-density VSP 8400 series Ethernet switch modules. By default, the VSP 8404 is a "zero port" system, with a chassis that integrates the switching fabric and all associated control and management electronics. Ethernet interfaces are delivered by the addition of one or more fieldreplaceable and hot-swappable Ethernet Switch Modules (ESMs).
