OEM#: STV100K10SNew OEM Original Outright

SURGE PROTECTION DEVICE 120/240VAC 1PH by Emerson Industrial

Your price:
$1,383.20 eachEstimated to ship by 12/31 if ordered before 4:30 PM EST
HomeEmerson Industrialstv100k10s
SURGE PROTECTION DEVICE 120/240VAC 1PH by Emerson Industrial
SURGE PROTECTION DEVICE 120/240VAC 1PH by Emerson Industrial

OEM#: STV100K10S
SURGE PROTECTION DEVICE 120/240VAC 1PH by Emerson Industrial

New OEM Original Outright
Your price:
$1,383.20 each
Estimated to ship by 12/31 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: STV100K10S Key Specs
Item
SURGE PROTECTION DEVICE 120/240VAC 1PH
OEM
Emerson Industrial
OEM #
STV100K10S
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Basic Material
Metallic
Chase Nipple Size
1/2 in
Country of Origin
Mexico
Depth
3.2 in
Enclosure Material
Metal
Enclosure NEMA Rating
12
Green Environmental Attribute
Does not Contain Reproductive or Developmental Toxins (as Per State of CA List), Endocrine Disrupters (as Per European Union Priority For Research List), Asthmagens (as Per AOEC List), Carcinogens (as Per IARC 1-2A-2B Lists)
Includes
Audible Alarm, LED Status Indicator
Length
6 in
Max Continuing Operating Voltage
150/300V AC
Max Operating Temperature
140 Degrees F
Max Surge Current per Mode
50kA (L-N, L-G, N-G)
Max Surge Current per Phase
100 kA
Min Operating Temperature
-40 Degrees F
Modes of Protection
L-G, L-L, L-N, N-G
Modular
No
Mounting Location
Externally Mounted
Mounting Style
Chase Nipple
Noise Attenuation
40dB
Nominal Discharge Current
20 kA
Number of Poles
2
Number of Wires
3 Wires + Ground
Phase
1
Short Circuit Current Rating
100kA
Standards
RoHS, Type 2, cULus Listed
System Connection
Parallel
UL SPD Type
Type 2
Voltage
120/240V AC
Voltage Protection Rating
600V (L-N), 700V (L-G, N-G), 1000V (L-L)
Width
4 in
Wire Gauge
12 AWG
