P/N: 641-12-LED Key Specs
Item
AIR VELOCITY TRANSMITTER
Condition
New OEM Original
Manufacturers Warranty Length
1
Max Pressure (PSI)
100 psi
Operating Temperature
Process: -40 to 212 Degrees F (-40 to 100 Degrees C) Ambient: 32 to 140 Degrees F (0 to 60 Degrees C)
Power Required
12 to 35 VDC, 10 to 16 VAC 1.5A Rating Required on Supply Due to Initial Power Surge Drawn by Transmitter
Probe Length (Inches)
12 in
Response Time (Seconds)
1.5 Seconds to 95% of Final Value (Output Filter Set to Minimum)
Velocity Accuracy
3% FS Process gas: 32 to 122 Degrees F (0 to 50 Degrees C); 4% FS Process gas: -40 to 32 Degrees F & 122 to 212 Degrees F (-40 to 0 Degrees C & 50 to 100 Degrees C)
Velocity Ranges
FPM: 250, 500, 1000, 2000, 3000, 5000, 10000, 15000
