OEM#: 4WNZ5New OEM Original Outright
FARM DUTY MTR CS TEAO 3/4 HP 1725 RPM 56 by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$452.55 eachEstimated to ship by 11/28 if ordered before 4:30 PM EST
OEM#: 4WNZ5FARM DUTY MTR CS TEAO 3/4 HP 1725 RPM 56 by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$452.55 each
Estimated to ship by 11/28 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 4WNZ5 Key Specs
Item
FARM DUTY MTR CS TEAO 3/4 HP 1725 RPM 56
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
4WNZ5
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Capacitor Required
Included
Country of Origin
Mexico
Duty
Continuous Air Over
Finish
Enamel
Frame
56
Full Load Amps
6.1/3.4-3.1
HP
3/4
Hz
60
Includes
Conduit Box, Gasketed Capacitor Cover, Shaft Key and Shaft Slinger
Ins. Class
B
Item - Farm Duty Motors
Agricultural Fan Motor
Length Less Shaft
9-15/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
Farm Duty
Motor Bearings
Ball
Motor Design
Capacitor-Start/Run
Motor Enclosure Design
Totally Enclosed Air-Over
Motor Frame Material
Rolled Steel
Motor Mounting Position
Horizontal
Motor Mounting Type
Cradle Base
Motor Service Factor
1.3
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Poultry/Livestock Belt Drive Fan
Motor Thermal Protection
Auto
Nameplate RPM
1725
Nominal Efficiency
81.2 %
Overall Length
11-13/16 in
Phase
1
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA Certified (258501), UL Recognized (E37403)
Voltage
115/208-230
Voltage Compatibility
115, 115/208-230, 115/230, 120, 120/240, 208, 208-230, 208-240, 230, 240
