OEM#: 3K617BGNew OEM Original Outright
MOTOR 3/4 HP 1725 RPM 115/208-230 V by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$384.06 eachEstimated to ship by 12/31 if ordered before 4:30 PM EST
OEM#: 3K617BGMOTOR 3/4 HP 1725 RPM 115/208-230 V by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$384.06 each
Estimated to ship by 12/31 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 3K617BG Key Specs
Item
MOTOR 3/4 HP 1725 RPM 115/208-230 V
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
3K617BG
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Body Diameter
6-1/2 in
Duty
Continuous
Frame
56H
Full Load Amps
11.2/5.6-5.6
HP
3/4
Hz
60
Includes
Shaft Key
Ins. Class
F
Length Less Shaft
9-3/8 in
Max Ambient Temperature
40 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
Split-Phase
Motor Enclosure Design
Open Dripproof
Motor Frame Material
Rolled Steel
Motor Mounting Position
All Angle
Motor Mounting Type
Cradle Base
Motor Service Factor
1.25
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Belt Drive Fan/Blower
Motor Thermal Protection
Auto
Nameplate RPM
1725
Nominal Efficiency
65.9 %
Number of Speeds
1
Overall Length
11-1/4 in
Phase
1
Resilient Ring Diameter
2-1/4 in
Ring to Ring Center
8-15/16 in
Shaft Diameter
5/8 in
Shaft Length
1-7/8 in
Standards
CSA Certified (258501), UL Recognized (E37403)
Voltage
115/208-230
Voltage Compatibility
115, 115/208-230, 115/230, 120, 120/240, 208, 208-230, 208-240, 230, 240
