OEM#: 31TR62New OEM Original Outright
FAN MTR 1 HP 1140 220-230/460 by DAYTON ELECTRIC MANUFACTURING CO
Your price:
$541.70 eachEstimated to ship by 12/02 if ordered before 4:30 PM EST
OEM#: 31TR62FAN MTR 1 HP 1140 220-230/460 by DAYTON ELECTRIC MANUFACTURING CO
New OEM Original Outright
Your price:
$541.70 each
Estimated to ship by 12/02 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 31TR62 Key Specs
Item
FAN MTR 1 HP 1140 220-230/460
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
31TR62
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Application
Condenser Fan
Body Diameter
5-1/2 in
Bolt Circle Diameter
1/2 in
Capacitor Required
No
Country of Origin
Mexico
Duty
Continuous
Frame
48Y
Full Load Amps
3.5-3.3/1.7
HP
1
Hz
60
Ins. Class
B
Lead Length
6 in
Length Less Shaft
1/2 in
Max Ambient Temperature
60 Degrees C
Motor Application
HVAC/R
Motor Bearings
Ball
Motor Design
3-Phase
Motor Enclosure Design
Open Air-Over
Motor Mounting Position
Vertical Shaft Up
Motor Mounting Type
Band
Motor Service Factor
1
Motor Shaft Design
Flat
Motor Shaft Rotation
CW/CCW
Motor Sub Application
Condenser Fan
Motor Thermal Protection
Auto
Mounting Stud Pattern
4 1/8 in x 4 1/8 in
Nameplate RPM
1140
Nominal Efficiency
83.4%
Number of Speeds
1
Overall Length
15-3/4 in
Phase
3
Shaft Diameter
1/2 in
Shaft Length
5 in
Standards
CSA 258525, UL E47479
Voltage
200-230/460
