OEM#: 1TDR9New OEM Original Outright

BLOWER 463 CFM 115V 1.28A 1600 RPM by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$172.47 eachEstimated to ship by 11/28 if ordered before 4:30 PM EST
HomeDAYTON ELECTRIC MANUFACTURING CO1tdr9
BLOWER 463 CFM 115V 1.28A 1600 RPM by DAYTON ELECTRIC MANUFACTURING CO
BLOWER 463 CFM 115V 1.28A 1600 RPM by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 1TDR9
BLOWER 463 CFM 115V 1.28A 1600 RPM by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$172.47 each
Estimated to ship by 11/28 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: 1TDR9 Key Specs
Item
BLOWER 463 CFM 115V 1.28A 1600 RPM
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
1TDR9
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Agency Compliance
cULus Recognized (E47479) for the Motor Only Not the Blower, CE and RoHS Compliance
Bearing Type
Ball
Blower Conduit Box
No
Blower Item
OEM Specialty Blower
Blower Motor Type
Permanent Split Capacitor
Blower Outlet Shape
Rectangular
Blower Thermal Protection
Auto
Blower Voltage
115V AC
Blower Wheel Diameter
5-1/8 in
Blower Wheel Width
7 in
CFM @ 0.000 in SP
463
CFM @ 0.100 in SP
425
CFM @ 0.200 in SP
388
CFM @ 0.300 in SP
338
CFM @ 0.400 in SP
250
CFM @ 0.500 in SP
161
CFM @ 0.600 in SP
50
Dimension A
8-9/16 in
Dimension B
10-1/2 in
Dimension C
9-3/16 in
Dimension D
8-3/16 in
Dimension E
9-3/8 in
Dimension F
3-5/16 in
Dimension J
9-7/16 in
Dimension K
5 in
Dimension L
8-13/16 in
Dimension M
4-3/8 in
Drive Type
Direct
Full Load Amps
1.28
Housing Color
Gray
Housing Finish
Enamel
Housing Material
Rolled Steel
Hz
50/60
Includes
Discharge Mounting Flange
Inlet Diameter
4-9/16 in
Lead Length
13 in
Max Ambient Temperature
104 Degrees F
Max Inlet Temperature
104 Degrees F
Motor Enclosure
Open
Motor Insulation
Class B
Mounting Position
All Position
Outlet Height
3-1/2 in
Outlet Width
7-13/16 in
Overall Depth
8-9/16 in
Overall Height
9-3/8 in
Overall Width
9-3/16 in
Phase
1
RPM
1600
Replaces
4C448
Wheel Type
Forward Curve
With Flange
Yes
