OEM#: 1TDP8New OEM Original Outright

BLOWER 184 CFM 115V 0.72A 3150 RPM by DAYTON ELECTRIC MANUFACTURING CO

Your price:
$145.98 eachReady to ship
HomeDAYTON ELECTRIC MANUFACTURING CO1tdp8
BLOWER 184 CFM 115V 0.72A 3150 RPM by DAYTON ELECTRIC MANUFACTURING CO
BLOWER 184 CFM 115V 0.72A 3150 RPM by DAYTON ELECTRIC MANUFACTURING CO

OEM#: 1TDP8
BLOWER 184 CFM 115V 0.72A 3150 RPM by DAYTON ELECTRIC MANUFACTURING CO

New OEM Original Outright
Your price:
$145.98 each
Ready to ship
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: 1TDP8 Key Specs
Item
BLOWER 184 CFM 115V 0.72A 3150 RPM
OEM
DAYTON ELECTRIC MANUFACTURING CO
OEM #
1TDP8
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Agency Compliance
cULus Recognized (E47479) for the Motor Only Not the Blower, CE and RoHS Compliance
Bearing Type
Ball
Blower Conduit Box
Yes
Blower Item
OEM Specialty Blower
Blower Motor Type
Permanent Split Capacitor
Blower Outlet Shape
Rectangular
Blower Thermal Protection
Auto
Blower Voltage
115V AC
Blower Wheel Diameter
2-15/16 in
Blower Wheel Width
1-7/8 in
CFM @ 0.000 in SP
184
CFM @ 0.100 in SP
178
CFM @ 0.200 in SP
170
CFM @ 0.300 in SP
158
CFM @ 0.400 in SP
140
CFM @ 0.500 in SP
120
Country of Origin
China
Dimension A
5-3/8 in
Dimension B
6-3/8 in
Dimension C
8-7/16 in
Dimension D
2-3/4 in
Dimension E
6-3/8 in
Dimension F
3-5/16 in
Dimension J
4-1/16 in
Dimension K
3-9/16 in
Dimension L
3-3/8 in
Dimension M
2-7/8 in
Drive Type
Direct
Full Load Amps
0.72
Housing Color
Gray
Housing Finish
Enamel
Housing Material
Rolled Steel
Hz
50/60
Includes
Discharge Mounting Flange
Inlet Diameter
2-5/8 in
Lead Length
13 in
Max Ambient Temperature
104 Degrees F
Max Inlet Temperature
104 Degrees F
Motor Enclosure
Open
Motor Insulation
Class B
Mounting Position
All Position
Outlet Height
2-1/8 in
Outlet Width
2-11/16 in
Overall Depth
5-3/8 in
Overall Height
5-3/4 in
Overall Width
8-7/16 in
Phase
1
RPM
3150
Replaces
4C015
Wheel Type
Forward Curve
With Flange
Yes
