OEM#: 2031069-015New OEM Original Outright

UI CONNECTION UPDATE ACQUISITION MAIN PDM FLEX ASSEMBLY by Datex-Ohmeda

Your price:
$949.04 eachWe are currently unable to provide a shipping date
HomeDatex-Ohmeda2031069015
BUYING OPTIONS:
New OEM Original
Outright Purchase
$949.04 each
Warranty: 90 Day
Refurbished
Outright Purchase
$2,267.44 each
Warranty: 6 Month
UI CONNECTION UPDATE ACQUISITION MAIN PDM FLEX ASSEMBLY by Datex-Ohmeda
UI CONNECTION UPDATE ACQUISITION MAIN PDM FLEX ASSEMBLY by Datex-Ohmeda

OEM#: 2031069-015
UI CONNECTION UPDATE ACQUISITION MAIN PDM FLEX ASSEMBLY by Datex-Ohmeda

New OEM Original Outright
Your price:
$949.04 each
We are currently unable to provide a shipping date
Asset Information

Not For Export Out Of US

ADD TO LIST
Product Overview

Patient data module (pdm) flex assembly is a custom designed main flex circuit assembly for use in patient data module (pdm) equipment. It interfaces with the mainboard, iso board, nbp pneumatic assembly, battery, user interface (ui) board and eport connector. The kit is comprised of das rear cover gasket eport system, main flex circuit assembly, six connectors, flex circuit, backerboard, carton bag, label and instruction manual. The flex assembly is made up of special material that has excellent chemical, radiation and corona resistance property, which makes it well suited for many medical applications. The flex circuit film is embedded with standard wire or ribbon cable to form reliable electrical wire circuit assembly. Due to its compact design and easy handling, the assembly is used as a field replacement.

  • Excellent chemical resistance
  • Good radiation resistance
  • Compact design
  • Rigid and flexible PCB
  • Tested to ASTM and IPC-4101 class C standard
  • Flammability rating UL94V-0
  • Complies to electrical safety standards

    • Features
    • Polyimide film flex circuit assembly
    • Highly reliable interface
    • Two conductive flexible layer design
    • Excellent physical, electrical and mechanical properties over a wide temperature range
    Technical Specs
    P/N: 2031069-015 Key Specs
    Item
    UI CONNECTION UPDATE ACQUISITION MAIN PDM FLEX ASSEMBLY
    OEM
    Datex-Ohmeda
    OEM #
    2031069-015
    Condition
    New OEM Original
    Returnable
    No
    Warranty
    90 Day
    Flammability Rating
    UL94V-0
    Equivalents

    Patient data module (pdm) flex assembly is a custom designed main flex circuit assembly for use in patient data module (pdm) equipment. It interfaces with the mainboard, iso board, nbp pneumatic assembly, battery, user interface (ui) board and eport connector. The kit is comprised of das rear cover gasket eport system, main flex circuit assembly, six connectors, flex circuit, backerboard, carton bag, label and instruction manual. The flex assembly is made up of special material that has excellent chemical, radiation and corona resistance property, which makes it well suited for many medical applications. The flex circuit film is embedded with standard wire or ribbon cable to form reliable electrical wire circuit assembly. Due to its compact design and easy handling, the assembly is used as a field replacement.

  • Excellent chemical resistance
  • Good radiation resistance
  • Compact design
  • Rigid and flexible PCB
  • Tested to ASTM and IPC-4101 class C standard
  • Flammability rating UL94V-0
  • Complies to electrical safety standards

    • 2026416-002: GE Medical Systems Information Technology (GEMSIT): Item Replacement
    • 2026416-004: GE Medical Systems Information Technology (GEMSIT): Item Replacement
    • 2031069-013: GE Healthcare: Item Replacement
    • 2031069-013: Marquette (GEMSIT): Item Replacement
    • 2031069-013: GE Medical Systems Information Technology (GEMSIT): Item Replacement
