OEM#: 1006-3245-000-SNew OEM Original Outright
AC INLET MODULE PRINTED CIRCUIT BOARD ASSEMBLY, 100 TO 120 V by Datex-Ohmeda
Your price:
$404.67 eachEstimated to ship by 11/27 if ordered before 4:00 PM EST
OEM#: 1006-3245-000-SAC INLET MODULE PRINTED CIRCUIT BOARD ASSEMBLY, 100 TO 120 V by Datex-Ohmeda
New OEM Original Outright
Your price:
$404.67 each
Estimated to ship by 11/27 if ordered before 4:00 PM EST
Asset Information
Drop Shipped From GE - Not For Export Out Of US
ADD TO LIST
Product Overview
This printed circuit assembly (pca) inrush is used in the alternating current (ac) inlet of anesthesia systems.The printed circuit board (pcb) has two sides -- one side is a component side and the other side is solder side.The component side contains a layer of engraved ink tracks that identify components, test points, warning symbols, logos and marks.The solder side is masked for protection against oxidation and to prevent solder bridges from forming between closely spaced solder pads. The pca on the soldered side includes faston terminals,fuse,resistor,transient voltage suppressor (tvs) diode,gas discharge tube arrestor, thermally protected varistors, thermal fuse resistor and adhesive to secure thermal fuse resistor.This printed circuit assembly (pca) is compatible with aespire 7900, aestiva 7900, and aestiva 7100 anesthesia delivery systems and carescape r86 ventilator system.
Technical Specs
P/N: 1006-3245-000-S Key Specs
Item
AC INLET MODULE PRINTED CIRCUIT BOARD ASSEMBLY, 100 TO 120 V
OEM
Datex-Ohmeda
OEM #
1006-3245-000-S
Condition
New OEM Original
Returnable
No
Warranty
90 Day
Power Requirements
100 to 120 V
Fitments
This printed circuit assembly (pca) inrush is used in the alternating current (ac) inlet of anesthesia systems.The printed circuit board (pcb) has two sides -- one side is a component side and the other side is solder side.The component side contains a layer of engraved ink tracks that identify components, test points, warning symbols, logos and marks.The solder side is masked for protection against oxidation and to prevent solder bridges from forming between closely spaced solder pads. The pca on the soldered side includes faston terminals,fuse,resistor,transient voltage suppressor (tvs) diode,gas discharge tube arrestor, thermally protected varistors, thermal fuse resistor and adhesive to secure thermal fuse resistor.This printed circuit assembly (pca) is compatible with aespire 7900, aestiva 7900, and aestiva 7100 anesthesia delivery systems and carescape r86 ventilator system.
- Datex-Ohmeda
- AESPIRE 7900
- ENGSTROM
- AESTIVA
- AESTIVA 7100
- AESTIVA 7900
- R860
