OEM#: PDU24002New OEM Original Outright
METERED ATS SERIES PDU24002, POWER DISTRIBUTION UNIT (RACK-MOUNTABLE), AC 100-120 V, 1-PHASE, SERIAL, INPUT: 2 X NEMA L5-20P, OUTPUT CONNECT by CyberPower
Your price:
$556.38 each
View All
OEM#: PDU24002METERED ATS SERIES PDU24002, POWER DISTRIBUTION UNIT (RACK-MOUNTABLE), AC 100-120 V, 1-PHASE, SERIAL, INPUT: 2 X NEMA L5-20P, OUTPUT CONNECT by CyberPower
New OEM Original Outright
Your price:
$556.38 each
CyberPower Metered ATS Series PDU24002 - power distribution unit
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Ensure continued operation of critical devices with the CyberPower PDU24002 Metered ATS PDU. Ideal for data centers and network closets, this unit provides power redundancy to single-corded connected equipment. If power for the primary source exceeds the lower or upper thresholds, or if power fails, the PDU will switch to the secondary power source to ensure continuous operation. The PDU will switch back to the primary power source when incoming power becomes stable.
The PDU24002 supports inputs between 100-120V and includes (10) NEMA 5-20R outlets. Dual NEMA L5-20P (L5-20P to non-locking 5-20P adpaters included) power cords are plugged into separate power sources (A and B), and information about each power source is provided via LED indicator lights on the front of the unit. Other features include an LCD with selectable background color, ugradeable firmware, and network-grade plugs and outlets. The CyberPower PDU24002 is protected by a three-year limited warranty.
What's in the Box: PDU, (2) Mounting Brackets, (24) M4 x 8 Bracket Mounting Screws, (6) M5 x 12 Rack Mounting Screws / (6) Washers, Cord Retention Tray, (6) M3 x 6 Cord Retention Tray Mounting Screws, (18) Cable Ties, RJ45/DB9 Serial Port Connection Cable, NEMA L5-20P to NEMA 5-20P Adapter, User's Manual
The PDU24002 supports inputs between 100-120V and includes (10) NEMA 5-20R outlets. Dual NEMA L5-20P (L5-20P to non-locking 5-20P adpaters included) power cords are plugged into separate power sources (A and B), and information about each power source is provided via LED indicator lights on the front of the unit. Other features include an LCD with selectable background color, ugradeable firmware, and network-grade plugs and outlets. The CyberPower PDU24002 is protected by a three-year limited warranty.
What's in the Box: PDU, (2) Mounting Brackets, (24) M4 x 8 Bracket Mounting Screws, (6) M5 x 12 Rack Mounting Screws / (6) Washers, Cord Retention Tray, (6) M3 x 6 Cord Retention Tray Mounting Screws, (18) Cable Ties, RJ45/DB9 Serial Port Connection Cable, NEMA L5-20P to NEMA 5-20P Adapter, User's Manual
Features
- Phase: Single, Amps: 20A (Derated to 16A), Volts: 100-120V, Frequency: 50/60Hz, Plug type: 2 x NEMA L5-20P (L5-20P to 5-20P adapter included)
Technical Specs
P/N: PDU24002 Key Specs
Item
METERED ATS SERIES PDU24002, POWER DISTRIBUTION UNIT (RACK-MOUNTABLE), AC 100-120 V, 1-PHASE, SERIAL, INPUT: 2 X NEMA L5-20P, OUTPUT CONNECT
OEM
CyberPower
OEM #
PDU24002
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Color
Black
Cord Length
10 ft
Device Type
Power distribution unit - rack-mountable
Dimensions (WxDxH)
17.1 in x 8.4 in x 1.8 in
Included Accessories
Cord retention tray
Input Connectors
2 x 2 x power NEMA L5-20P
Input Voltage
AC 100-120 V
Input Wiring
1-phase
Networking
Serial
Output Voltage
AC 100-120 V
Output connectors
10 x power NEMA 5-20R
Rack Size
1U
Weight
10.6 lbs
Ensure continued operation of critical devices with the CyberPower PDU24002 Metered ATS PDU. Ideal for data centers and network closets, this unit provides power redundancy to single-corded connected equipment. If power for the primary source exceeds the lower or upper thresholds, or if power fails, the PDU will switch to the secondary power source to ensure continuous operation. The PDU will switch back to the primary power source when incoming power becomes stable.
The PDU24002 supports inputs between 100-120V and includes (10) NEMA 5-20R outlets. Dual NEMA L5-20P (L5-20P to non-locking 5-20P adpaters included) power cords are plugged into separate power sources (A and B), and information about each power source is provided via LED indicator lights on the front of the unit. Other features include an LCD with selectable background color, ugradeable firmware, and network-grade plugs and outlets. The CyberPower PDU24002 is protected by a three-year limited warranty.
What's in the Box: PDU, (2) Mounting Brackets, (24) M4 x 8 Bracket Mounting Screws, (6) M5 x 12 Rack Mounting Screws / (6) Washers, Cord Retention Tray, (6) M3 x 6 Cord Retention Tray Mounting Screws, (18) Cable Ties, RJ45/DB9 Serial Port Connection Cable, NEMA L5-20P to NEMA 5-20P Adapter, User's Manual
The PDU24002 supports inputs between 100-120V and includes (10) NEMA 5-20R outlets. Dual NEMA L5-20P (L5-20P to non-locking 5-20P adpaters included) power cords are plugged into separate power sources (A and B), and information about each power source is provided via LED indicator lights on the front of the unit. Other features include an LCD with selectable background color, ugradeable firmware, and network-grade plugs and outlets. The CyberPower PDU24002 is protected by a three-year limited warranty.
What's in the Box: PDU, (2) Mounting Brackets, (24) M4 x 8 Bracket Mounting Screws, (6) M5 x 12 Rack Mounting Screws / (6) Washers, Cord Retention Tray, (6) M3 x 6 Cord Retention Tray Mounting Screws, (18) Cable Ties, RJ45/DB9 Serial Port Connection Cable, NEMA L5-20P to NEMA 5-20P Adapter, User's Manual
