OEM#: 0945.70NG.SNew OEM Original Outright
OMEGA II NATURAL GAS INFRARED HEATER STRAIGHT TUBE - - 200000 BTU by Combustion Research Corporation
Your price:
$2,003.72 eachEstimated to ship by 12/23 if ordered before 10:30 AM EST
OEM#: 0945.70NG.SOMEGA II NATURAL GAS INFRARED HEATER STRAIGHT TUBE - - 200000 BTU by Combustion Research Corporation
New OEM Original Outright
Your price:
$2,003.72 each
Estimated to ship by 12/23 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Omega II Commercial radiant infrared tube heater the original dry tube gas fired system manufactured in US by Combustion Research. 200000 BTU power vented system with 4" OD emitter tube that runs on natural gas pre engineered, gas fired, unitary power vented (also known as positive pressure or push through systems) 70' straight configuration systems package. Energy savings of 30-50% over conventional heating systems. Each system includes a powder coated aluminized steel burner. Also comes standard bright finish aluminum reflectors, tube & reflector hangers and intermediate supports, heat treated aluminized steel radiant tubes, joint sealer, screws, turbulator, stainless steel flexible gas connector with manual gas valve (US Only) and two reflector end caps. For use commercial and industrial applications other common uses include aircraft hangers, large warehouses, animal confinement, oil & lube shops, auto dealerships, patio's, brooders, pole barns, bump shops, service garages, car & truck wash bays, shipping & receiving docks, commercial applications, steel warehousing, greenhouses, swimming pools, industrial applications, warehouses, and more. CSA Certified.
Technical Specs
P/N: 0945.70NG.S Key Specs
Item
OMEGA II NATURAL GAS INFRARED HEATER STRAIGHT TUBE - - 200000 BTU
OEM
Combustion Research Corporation
OEM #
0945.70NG.S
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Amps High
1.4
Application
Commercial, Industrial
Btu High
200000
Burner Pressure W.C. Inches
3-1/2
Clearance To Combustibles Bottom Inches
80
Clearance To Combustibles Side Inches
48
Clearance To Combustibles Top Inches
7
Color
White
Connection Type
NPT Stainless Steel Gas Flex
Construction
Aluminum Reflectors / Aluminized Steel Emitter Tubes
Country of Origin
USA
Coverage Square Feet
3330
Duct Size Inches
4
Fuel Type
Natural Gas
Gas Inlet Pressure Max. Water Column Inches
14
Gas Inlet Pressure Min. Water Column Inches
6
Height Inches
10-1/2
Hertz (Hz)
60
Horsepower
1/25
Ignition Type
Direct Spark
Length Feet
70-7/16
Limited Warranty Years
Burner 3; Tube 10
Listing, Rating, Certification
CSA
Manufacturer Part#
0945.70NG.S
Maximum Mounting Height Feet
40
Minimum Mounting Height Feet
17
Mount Type
Celling Suspension
Npt Inches
1/2
Phase
1
Power Cord Type
Hard Wired
Shape
Straight
Tube Construction
Aluminized Steel
Tube Length Feet
70
Type
Power Vented Infrared Tube Heater
Voltage
110
Watts High
58614
Weight Lbs
194
Width Inches
13-1/2
Wire Size
18-Gauge
Omega II Commercial radiant infrared tube heater the original dry tube gas fired system manufactured in US by Combustion Research. 200000 BTU power vented system with 4" OD emitter tube that runs on natural gas pre engineered, gas fired, unitary power vented (also known as positive pressure or push through systems) 70' straight configuration systems package. Energy savings of 30-50% over conventional heating systems. Each system includes a powder coated aluminized steel burner. Also comes standard bright finish aluminum reflectors, tube & reflector hangers and intermediate supports, heat treated aluminized steel radiant tubes, joint sealer, screws, turbulator, stainless steel flexible gas connector with manual gas valve (US Only) and two reflector end caps. For use commercial and industrial applications other common uses include aircraft hangers, large warehouses, animal confinement, oil & lube shops, auto dealerships, patio's, brooders, pole barns, bump shops, service garages, car & truck wash bays, shipping & receiving docks, commercial applications, steel warehousing, greenhouses, swimming pools, industrial applications, warehouses, and more. CSA Certified.
