OEM#: F-PFD1-1622S34New OEM Original Outright

INDUSTRIAL HVLS FAN by Big Ass Fans

Your price:
$14,050.70 each
$14,147.64 Savings: $96.94 (1%)
Estimated to ship by 01/06 if ordered before 4:30 PM EST
HomeBig Ass Fansfpfd11622s34
INDUSTRIAL HVLS FAN by Big Ass Fans
INDUSTRIAL HVLS FAN by Big Ass Fans

OEM#: F-PFD1-1622S34
INDUSTRIAL HVLS FAN by Big Ass Fans

New OEM Original Outright
Your price:
$14,050.70 each
$14,147.64 Savings: $96.94 (1%)
Estimated to ship by 01/06 if ordered before 4:30 PM EST
Asset Information
ADD TO LIST
Technical Specs
P/N: F-PFD1-1622S34 Key Specs
Item
INDUSTRIAL HVLS FAN
OEM
Big Ass Fans
OEM #
F-PFD1-1622S34
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Air Flow
138,670 cfm
Amps
7.55 A
Area Covered (Cooling) - Fans
15,000 sq ft
Area Covered (Destratification) - Fans
15,000 sq ft
Bearing Type
Permanently Lubricated, Double Sealed, SKF ball bearing
Blade Diameter
16 ft
Blade Finish
Anodized Aluminum
Blade Material
Aluminum
Country of Origin
USA
Down Rod Outside Dia.
36 in
Environmental Applications
Industrial
Fan Blade Color
Silver
Fan Housing Color
Yellow
Fan Mounting Location
I Beam, Spanning Trusses or Joists
Fan Watts
1,443 W
Housing Finish
Powder Coated
Hz
50/60 Hz
Includes
Airfoils, Controller, Drop Tube, Fan Motor Assembly, Mount, Safety Cable
Light Kit
None
Max. Ambient Temp.
131 Degrees F
Max. Mounting Height
29 ft
Min. Mounting Height
21 ft
Motor Design
Brushless Direct Drive
Motor Enclosure
Brushless Direct Drive
Motor HP
1 1/2 hp
Motor Insulation
Class F
Mount Type
Bracket
Number of Blades
6
Number of Speeds
Variable
Phase
1, 3
RPM
108
Reversible
Yes
Sound Level
35 dBA
Speed Controllable - Fans
Yes
Standards
CSA Standard 22.2 No. 113, UL Standard 507
Thermal Protection
Auto
Voltage
200 to 277V AC
