OEM#: SA-2010S-INTLNew OEM Original Outright
10 PATIENT LEADS AND SIMULATOR SAFETY ANALYZER by BC Group International, Inc. (BC Biomedical)
Your price:
$2,950.14 eachEstimated to ship by 12/02 if ordered before 11:30 AM EST
OEM#: SA-2010S-INTL10 PATIENT LEADS AND SIMULATOR SAFETY ANALYZER by BC Group International, Inc. (BC Biomedical)
New OEM Original Outright
Your price:
$2,950.14 each
Estimated to ship by 12/02 if ordered before 11:30 AM EST
Asset Information
ADD TO LIST
Product Overview
The microprocessor-based electrical safety analyzer with a built-in patient simulator. It allows for a multitude of tests to be performed on a device using the same unit and lead connections. It provides all the features of an electrical safety analyzer, as well as ECG Simulation with four waveforms (with constant QRS duration) and six machine performance testing waveforms. There is Patient Lead testing for 10 inputs.
- Led status indicators
- Audio feedback
- Touch control keys – no knobs
- 10 universal patient lead inputs
- High impact plastic case
Safety Analyzer Capabilities:
- CLine voltage measurement
- Device under test current measurement
- Earth / ground lead resistance
- Earth / ground leakage current
- Enclosure / chassis leakage current
- External resistance
- External leakage current
- Source receptacle wiring integrity monitor
- True RMS measurements
- AAMI ES1-1993 or IEC 601 selectable test loads
- 85 to 265 VAC operation
- Full 20 amp rating
- Self test points
- Externally replaceable ground fuse
- Automatic load reversal delay
- Patient lead to lead leakage current
- Patient lead to earth / ground leakage current
- Patient isolation leakage current
- External isolation leakage current
Patient Simulator Capabilities:
- Sine: 10, 60 AND 100 HZ
- ECG: 30, 60, 120 AND 240 BPM
- Square: 0.125 AND 2.0 HZ
- Triangle: 2 HZ
- High level output (1 V p-p)
- Amplitude accuracy: +/- 2%
- Frequency accuracy: +/- 0.5%
Technical Specs
P/N: SA-2010S-INTL Key Specs
Item
10 PATIENT LEADS AND SIMULATOR SAFETY ANALYZER
OEM
BC Group International, Inc. (BC Biomedical)
OEM #
SA-2010S-INTL
Condition
New OEM Original
Returnable
Yes
Warranty
12 Month
Certification
NIST Traceable
Current
20 A
MAP(Isolation)
Yes
Open Line
Yes
Open Netural
Yes
Patient Leads
10
Reverse Polarity
Yes
Size
8.7 IN x 5.5 IN x 1.6 IN
Volts
85 to 265 V
