OEM#: ZDVSM3661TNew OEM Original Outright

MOTOR, 3HP, 1800RPM, 3PH, 60HZ, 182TC, TEFC, FOOT by BALDOR

Your price:
$4,659.06 eachEstimated to ship by 12/02 if ordered before 10:30 AM EST
HomeBALDORzdvsm3661t
MOTOR, 3HP, 1800RPM, 3PH, 60HZ, 182TC, TEFC, FOOT by BALDOR
MOTOR, 3HP, 1800RPM, 3PH, 60HZ, 182TC, TEFC, FOOT by BALDOR

OEM#: ZDVSM3661T
MOTOR, 3HP, 1800RPM, 3PH, 60HZ, 182TC, TEFC, FOOT by BALDOR

New OEM Original Outright
Your price:
$4,659.06 each
Estimated to ship by 12/02 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview

Baldor-Reliance Motor, 3HP,1800RPM,3PH,60HZ,182TC,TEFC,FOOT,

Features:

  • Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
  • Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
  • Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
  • Continuous constant torque to zero speed
Typical Applications:
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.

Technical Specs
P/N: ZDVSM3661T Key Specs
Item
MOTOR, 3HP, 1800RPM, 3PH, 60HZ, 182TC, TEFC, FOOT
OEM
BALDOR
OEM #
ZDVSM3661T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
ZDVSM3661T
Brg-De-Afbma
30BC02JP30X
Brg-Ode-Afbma
25BC02JP30X
C-Dimension Inches
15.62
Constant-Torq-Hertz
1000 1
Country of Origin
USA
Drive End Flange
C-Face
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Frame
182TC
Horsepower
3
Insulation Class
F
Is_Motor
Yes
Magnetizing-Current
2.8/1.4
Maximum-Rpm
6200
Motor Rpm 60Hz
1755
Motor-Base-Amps
7.6/3.8
Motor-Base-Hp
3
Motor-Base-Hz
60
Motor-Base-Rpm
1755
Motor-Base-Volts
230/460
Motor-Max-Amps
7.4/3.7
Motor-Max-Hp
3
Motor-Max-Hz
90
Motor-Max-Rpm
2630
Motor-Max-Volts
230/460
Phase
3
Poles
4
Reliance Number
E01384ACDL006
Rotor-Inertia
0.34
Rpm
1755
Rpm Range
1701-1800
Service Factor
1
Spec. Number
P18G1233
Temp. Code
2
Type
P
Voltage
230/460
Weight
125

Baldor-Reliance Motor, 3HP,1800RPM,3PH,60HZ,182TC,TEFC,FOOT,

Features:

  • Designed specifically for Inverter operation where up to 1000:1 constant torque speed range is required
  • Includes provisions for stub shaft for hollow shaft encoder, three thermostats, and all 440T frames include an ODE insulated bearing
  • Insulation system exceeds NEMA MG 1-2006, Part 31.4.4.2
  • Continuous constant torque to zero speed
Typical Applications:
Conveyors, extruders, printing lines, converting, test stands, anywhere constant torque is required over a wide speed range.
