OEM#: VEWDM3558TNew OEM Original Outright
MOTOR, 2HP, 1725RPM, 3PH, 60HZ, 145TC, 3532M, TEFC, F1 by BALDOR
Your price:
$1,563.91 eachEstimated to ship by 11/29 if ordered before 10:30 AM EST
OEM#: VEWDM3558TMOTOR, 2HP, 1725RPM, 3PH, 60HZ, 145TC, 3532M, TEFC, F1 by BALDOR
New OEM Original Outright
Your price:
$1,563.91 each
Estimated to ship by 11/29 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 2HP,1725RPM,3PH,60HZ,145TC,3532M,TEFC,F1
Features:
- Moisture sealant on bolt heads, between frame and endplates
- Neoprene gaskets
- Double sealed bearings
- Forsheda® running contact v-ring slinger
- Stainless steel shaft
- Electrostatically applied epoxy finish
- Class F insulation
- Tropicalized
Food processing and other applications where motor is regularly exposed to high pressure wash down.
Technical Specs
P/N: VEWDM3558T Key Specs
Item
MOTOR, 2HP, 1725RPM, 3PH, 60HZ, 145TC, 3532M, TEFC, F1
OEM
BALDOR
OEM #
VEWDM3558T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
VEWDM3558T
Bearing-Opp-Drive-End
6203
C-Dimension Inches
14.18
Country of Origin
USA
Drive End Flange
C-Face
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
6-5.8/2.9
Frame
145TC
Hertz
60
Horsepower
2
Is_Motor
Yes
Motor Rpm 60Hz
1755
Mounting
C-Face Footless
Phase
3
Poles
4
Rpm
1755
Rpm Range
1701-1800
Service Factor
1.15
Voltage
208-230/460
Weight
48
Baldor-Reliance Motor, 2HP,1725RPM,3PH,60HZ,145TC,3532M,TEFC,F1
Features:
- Moisture sealant on bolt heads, between frame and endplates
- Neoprene gaskets
- Double sealed bearings
- Forsheda® running contact v-ring slinger
- Stainless steel shaft
- Electrostatically applied epoxy finish
- Class F insulation
- Tropicalized
Food processing and other applications where motor is regularly exposed to high pressure wash down.
