OEM#: L3912TNew OEM Original Outright
SINGLE PHASE MOTOR, 15 HP, 208-230 VOLTS, 1760 RPM, TEFC, 256T FRAME by BALDOR
Your price:
$9,841.89 each
OEM#: L3912TSINGLE PHASE MOTOR, 15 HP, 208-230 VOLTS, 1760 RPM, TEFC, 256T FRAME by BALDOR
New OEM Original Outright
Your price:
$9,841.89 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Product Overview
Baldor-Reliance Single Phase Motor, L3912T, 15 HP, 208-230 Volts, 1760 RPM, TEFC, 256T Frame
In applications where only single phase power is utilized, these motors are available from 1/12 Hp through 15 Hp in TEFC and ODP designs. Standard foot mounted configurations are available, as well as C-Face foot mounted and C-Face footless. These are also offered in 1/4 Hp through 5 Hp as Super-E® Premium Efficient motors where energy savings is desired.
Features
In applications where only single phase power is utilized, these motors are available from 1/12 Hp through 15 Hp in TEFC and ODP designs. Standard foot mounted configurations are available, as well as C-Face foot mounted and C-Face footless. These are also offered in 1/4 Hp through 5 Hp as Super-E® Premium Efficient motors where energy savings is desired.
Features
- Heavy guage steel frames
- Ball bearings
- Base is seam welded to frame
- Snap Action starting switch for reliability
- General purpose including compressors, pumps, fans, farm equipment, conveyors, material handling equipment, machine tools, etc.
Technical Specs
P/N: L3912T Key Specs
Item
SINGLE PHASE MOTOR, 15 HP, 208-230 VOLTS, 1760 RPM, TEFC, 256T FRAME
OEM
BALDOR
OEM #
L3912T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
L3912T
Bearing-Drive-End
6309
Bearing-Opp-Drive-End
6307
C-Dimension Inches
24.56
Country of Origin
USA
Design Code
L
Duty
Continuous
Enclosure
TEFC
Enclosure Type
Totally Enclosed
Fl Amps
66-58
Fl Efficiency
86.5
Frame
256T
Hertz
60
Horsepower
15
Insulation Class
F
Is_Motor
Yes
Kva-Code
F
Motor Rpm 60Hz
1760
Mounting
Rigid
Nameplate Rpm
1760
Phase
1
Power-Factor
96
Rpm Range
1701-1800
Service Factor
1
Spec. Number
39T044X522G1
Type
Single Phase Motor
Voltage
208-230
Baldor-Reliance Single Phase Motor, L3912T, 15 HP, 208-230 Volts, 1760 RPM, TEFC, 256T Frame
In applications where only single phase power is utilized, these motors are available from 1/12 Hp through 15 Hp in TEFC and ODP designs. Standard foot mounted configurations are available, as well as C-Face foot mounted and C-Face footless. These are also offered in 1/4 Hp through 5 Hp as Super-E® Premium Efficient motors where energy savings is desired.
Features
In applications where only single phase power is utilized, these motors are available from 1/12 Hp through 15 Hp in TEFC and ODP designs. Standard foot mounted configurations are available, as well as C-Face foot mounted and C-Face footless. These are also offered in 1/4 Hp through 5 Hp as Super-E® Premium Efficient motors where energy savings is desired.
Features
- Heavy guage steel frames
- Ball bearings
- Base is seam welded to frame
- Snap Action starting switch for reliability
- General purpose including compressors, pumps, fans, farm equipment, conveyors, material handling equipment, machine tools, etc.
Product Overview
Baldor-Reliance Single Phase Motor, L3912T, 15 HP, 208-230 Volts, 1760 RPM, TEFC, 256T Frame
In applications where only single phase power is utilized, these motors are available from 1/12 Hp through 15 Hp in TEFC and ODP designs. Standard foot mounted configurations are available, as well as C-Face foot mounted and C-Face footless. These are also offered in 1/4 Hp through 5 Hp as Super-E® Premium Efficient motors where energy savings is desired.
Features
In applications where only single phase power is utilized, these motors are available from 1/12 Hp through 15 Hp in TEFC and ODP designs. Standard foot mounted configurations are available, as well as C-Face foot mounted and C-Face footless. These are also offered in 1/4 Hp through 5 Hp as Super-E® Premium Efficient motors where energy savings is desired.
Features
- Heavy guage steel frames
- Ball bearings
- Base is seam welded to frame
- Snap Action starting switch for reliability
- General purpose including compressors, pumps, fans, farm equipment, conveyors, material handling equipment, machine tools, etc.
