OEM#: IDNM3770TNew OEM Original Outright
MOTOR, 7.5HP, 1760RPM, 3PH, 60HZ, 213TC, 0750M, TENV by BALDOR
Your price:
$3,404.80 eachEstimated to ship by 12/02 if ordered before 10:30 AM EST
OEM#: IDNM3770TMOTOR, 7.5HP, 1760RPM, 3PH, 60HZ, 213TC, 0750M, TENV by BALDOR
New OEM Original Outright
Your price:
$3,404.80 each
Estimated to ship by 12/02 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 7.5HP,1760RPM,3PH,60HZ,213TC,0750M,TENV
Features:
- Motors include provisions for encoder feedback mounting when used with closed loop velocity or position motor controls
- Meets NEMA MG 1, Part 31
Conveyors, pumps, fans, metal processing, compressors, test stands, and material handling equipment. Designed for inverter or vector applications where up to a 1000:1 constant torque speed range is required.
Technical Specs
P/N: IDNM3770T Key Specs
Item
MOTOR, 7.5HP, 1760RPM, 3PH, 60HZ, 213TC, 0750M, TENV
OEM
BALDOR
OEM #
IDNM3770T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
IDNM3770T
Bearing-Drive-End
6307
C-Dimension Inches
20.4
Country of Origin
USA
Design Code
A
Drive End Flange
C-Face
Enclosure
TENV
Enclosure Type
Totally Enclosed
Fl Amps
20.2/10.1
Fl Efficiency
91.7
Frame
213TC
Hertz
60
Horsepower
7 1/2
Insulation Class
H
Is_Motor
Yes
Magnetizing-Current
11/5.5
Maximum-Rpm
6000
Motor Rpm 60Hz
1760
Mounting
Rigid
Opposite End Bearing
6206
Phase
3
Poles
4
Rotor-Inertia
1.23
Rpm
1760
Rpm Range
1701-1800
Service Factor
1
Slip-Hertz
1
Spec. Number
07J135W747G1
Voltage
230/460
Weight
196
Baldor-Reliance Motor, 7.5HP,1760RPM,3PH,60HZ,213TC,0750M,TENV
Features:
- Motors include provisions for encoder feedback mounting when used with closed loop velocity or position motor controls
- Meets NEMA MG 1, Part 31
Conveyors, pumps, fans, metal processing, compressors, test stands, and material handling equipment. Designed for inverter or vector applications where up to a 1000:1 constant torque speed range is required.
