OEM#: IDM3584TNew OEM Original Outright

MOTOR, 1.5HP, 1760RPM, 3PH, 60HZ, 145TC, 0530M, TEBC by BALDOR

Your price:
$2,439.61 eachEstimated to ship by 10/31 if ordered before 10:30 AM EST
HomeBALDORidm3584t
MOTOR, 1.5HP, 1760RPM, 3PH, 60HZ, 145TC, 0530M, TEBC by BALDOR
MOTOR, 1.5HP, 1760RPM, 3PH, 60HZ, 145TC, 0530M, TEBC by BALDOR

OEM#: IDM3584T
MOTOR, 1.5HP, 1760RPM, 3PH, 60HZ, 145TC, 0530M, TEBC by BALDOR

New OEM Original Outright
Your price:
$2,439.61 each
Estimated to ship by 10/31 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview

Baldor-Reliance Motor, 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC

Features:

  • Motors include provisions for encoder feedback mounting when used with closed loop velocity or position motor controls
  • Meets NEMA MG 1, Part 31
Typical Applications:
Conveyors, pumps, fans, metal processing, compressors, test stands, and material handling equipment. Designed for inverter or vector applications where up to a 1000:1 constant torque speed range is required.

Technical Specs
P/N: IDM3584T Key Specs
Item
MOTOR, 1.5HP, 1760RPM, 3PH, 60HZ, 145TC, 0530M, TEBC
OEM
BALDOR
OEM #
IDM3584T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Baldor Catalog Number
IDM3584T
Bearing-Drive-End
6205
Blower-Amps
0.5
Blower-Hertz
60
Blower-Phase
1
Blower-Volts
115
C-Dimension Inches
19.15
Country of Origin
USA
Design Code
B
Drive End Flange
C-Face
Enclosure
TEBC
Enclosure Type
Totally Enclosed
Fl Amps
4.2/2.1
Fl Efficiency
88.5
Frame
145TC
Hertz
60
Horsepower
1 1/2
Insulation Class
H
Is_Motor
Yes
Magnetizing-Current
2.4/1.2
Maximum-Rpm
6000
Motor Rpm 60Hz
1760
Mounting
Rigid
Opposite End Bearing
6203
Phase
3
Poles
4
Rotor-Inertia
0.177
Rpm
1760
Rpm Range
1701-1800
Service Factor
1
Slip-Hertz
1.3
Spec. Number
05E535X008G1
Voltage
230/460
Weight
69

Baldor-Reliance Motor, 1.5HP,1760RPM,3PH,60HZ,145TC,0530M,TEBC

Features:

  • Motors include provisions for encoder feedback mounting when used with closed loop velocity or position motor controls
  • Meets NEMA MG 1, Part 31
Typical Applications:
Conveyors, pumps, fans, metal processing, compressors, test stands, and material handling equipment. Designed for inverter or vector applications where up to a 1000:1 constant torque speed range is required.
