OEM#: EM2549TNew OEM Original Outright
MOTOR, 75HP, 3540RPM, 3PH, 60HZ, 364TS, 4254M, OPSB, F by BALDOR
Your price:
$9,930.73 eachEstimated to ship by 12/26 if ordered before 10:30 AM EST
OEM#: EM2549TMOTOR, 75HP, 3540RPM, 3PH, 60HZ, 364TS, 4254M, OPSB, F by BALDOR
New OEM Original Outright
Your price:
$9,930.73 each
Estimated to ship by 12/26 if ordered before 10:30 AM EST
Asset Information
ADD TO LIST
Product Overview
Baldor-Reliance Motor, 75HP,3540RPM,3PH,60HZ,364TS,4254M,OPSB,F
Features:
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty.
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
Technical Specs
P/N: EM2549T Key Specs
Item
MOTOR, 75HP, 3540RPM, 3PH, 60HZ, 364TS, 4254M, OPSB, F
OEM
BALDOR
OEM #
EM2549T
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
Ambient Temp C
40
Bearing-Drive-End
6313
Bearing-Opp-Drive-End
6311
C-Dimension Inches
25.81
Country of Origin
USA
Design Code
B
Doe-Code
010A
Drive End Flange
Standard
Enclosure
OPSB
Enclosure Type
Open/Drip Proof
Fl Amps
178-164/82
Fl Efficiency
94.5
Frame
364TS
Grease
POLYREX EM
Hertz
60
Horsepower
75
Insulation Class
F
Is_Motor
Yes
Kva-Code
G
Motor Rpm 60Hz
3540
Mounting
Rigid
Nameplate Rpm
3540
Phase
3
Poles
2
Power-Factor
91
Rpm Range
3001-3600
Service Factor
1.15
Spec. Number
42E212W462
Voltage
208-230/460
Weight
507
Baldor-Reliance Motor, 75HP,3540RPM,3PH,60HZ,364TS,4254M,OPSB,F
Features:
- Heavy duty frames
- Ball bearings
- Moisture resistant ISR® (Inverter Spike Resistant) copper windings
- Low-loss electrical lamination grade steel
- Three year warranty.
Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.
