OEM#: L3607New OEM Original Outright
MOTOR 1 HP 1140 RPM 115/230V 184 TEFC by BALDOR
Your price:
$3,500.86 each
OEM#: L3607MOTOR 1 HP 1140 RPM 115/230V 184 TEFC by BALDOR
New OEM Original Outright
Your price:
$3,500.86 each
Asset Information
Are you an existing customer? Sign in to access your account.
ADD TO LIST
Technical Specs
P/N: L3607 Key Specs
Item
MOTOR 1 HP 1140 RPM 115/230V 184 TEFC
OEM
BALDOR
OEM #
L3607
Condition
New OEM Original
Returnable
No
Warranty
Mfr Warranty
CC Number
CC031A
Country of Origin
USA
Duty
Continuous
Frame
184
Full Load Amps
14/7
HP
1 hp
Hz
60
Includes
Conduit Box
Ins. Class
B
Length Less Shaft
13-7/16 in
Max Ambient Temperature
40 Degrees C
Motor Application
General Application
Motor Bearings
Ball
Motor Design
Capacitor-Start
Motor Efficiency Group
Energy Efficient
Motor Enclosure Design
Totally Enclosed Fan-Cooled
Motor Frame Material
Rolled Steel
Motor Mounting Type
Rigid Base
Motor Service Factor
1.15
Motor Shaft Design
Keyed
Motor Shaft Rotation
CW/CCW
Motor Thermal Protection
None
Nameplate RPM
1140
Nominal Efficiency
67 %
Number of Speeds
1
Overall Length
15-11/16 in
Phase
1
RPM Group
1101-1200
RPM Range
1101-1200
Shaft Diameter
7/8 in
Shaft Length
2-1/4 in
Standards
CSA, UL
Voltage
115/230
